Join/Prune FSM: [NI]
Assert FSM: [NI]
FSM information for non-downstream interfaces: None
Table 94 Command output
Field Descri
tion
Total 0 (*, G) entry; 1 (S, G) entry Total number of (S, G) entries and (*, G) entries.
(2001::2, FFE3::101) (S, G) entry.
Protocol IPv6 PIM mode: IPv6 PIM-SM or IPv6 PIM-DM.
Flag
Flag of the (S, G) entry or (*, G) entry:
• ACT—The entry has been used for routing data.
• DEL—The entry will be removed.
• EXPRUNE—Some outgoing interfaces are pruned by other IPv6
multicast routing protocols.
• EXT—The entry contains outgoing interfaces provided by other
multicast routing protocols.
• LOC—The entry is on a router directly connected to the same subnet
with the IPv6 multicast source.
• NIIF—The entry contains unknown incoming interfaces.
• NONBR—The entry has an IPv6 PIM neighbor lookup failure.
• RPT—The entry is on an RPT branch where (S, G) prunes have been
sent to the RP.
• SPT—The entry is on the SPT.
• SWT—The entry is in the process of R
• WC—The entry contains a wildcard.
PT-to-SPT switchover.
Uptime Length of time since the (S, G) entry or (*, G) entry was installed.
Upstream interface Upstream (incoming) interface of the (S, G) entry or (*, G) entry.
Upstream neighbor Upstream neighbor of the (S, G) entry or (*, G) entry.
RPF prime neighbor
RP neighbor of the (S, G) or (*, G) entry: F
• For a (*, G) entry, if the RPF neighbor is the RP, the field displays NULL.
• For an (S, G) entry, if the RPF neighbor is a router that directly connects
to the IPv6 multicast source, this field displays NULL.
Downstream interface(s)
information
.
aces.
• Expiration time of the downstream interfaces.
Inf rmation about the downstream interfaceso :
• Total number of downstream interfaces
• Names of the downstream interfaces.
• Protocol type on the downstream interf
• Uptime of the downstream interfaces.
Use display ipv6 pim rp-info to display RP information in the IPv6 PIM-SM domain.
display ipv6 pim rp-info
316
