include: Specifies the multicast forwarding entries that contain the specified interface in the outgoing
interface list.
match: Specifies the forwarding entries that contain only the specified interface in the outgoing interface
list.
slot slot-number: Specifies an IRF member device by its member ID or a PEX by its virtual slot number. If
you do not specify this option, the command displays multicast forwarding entries on the master device.
statistics: Displays statistics for the multicast forwarding entries.
Examples
# Display multicast forwarding entries on the public network.
<Sysname> display multicast forwarding-table
Total 1 entry, 1 matched
00001. (172.168.0.2, 227.0.0.1)
Flags: 0x0
Uptime: 00:08:32, Timeout in: 00:03:26
Incoming interface: Vlan-interface10
Incoming sub-VLAN: VLAN 11
Outgoing sub-VLAN: VLAN 12
VLAN 13
List of 1 outgoing interface:
1: Vlan-interface20
Sub-VLAN: VLAN 21
VLAN 22
Matched 19648 packets(20512512 bytes), Wrong If 0 packet
Forwarded 19648 packets(20512512 bytes)
Table 26 Command output
Field Descri
tion
Total 1 entry, 1 matched
Total number of (S, G) entries and total number of matching (S, G)
entries.
00001 Sequence number of the (S, G) entry.
(172.168.0.2,227.0.0.1) (S, G) entry.
Flags
Current state of the (S, G) entry. Different bits represent different
states of (S, G) entries. For values of this field, see Table 27.
Uptime Length of time for which the (S, G) entry has been up.
Timeout in Length of time in which the (S, G) entry will expire.
Incoming interface Incoming interface of the (S, G) entry.
Incoming sub-VLAN
Incoming sub-VLAN of the super VLAN when the incoming
interface of the (S, G) entry is the VLAN interface of this super
VLAN.
Outgoing sub-VLAN
Outgoing sub-VLAN of the super VLAN when the incoming
interface of the (S, G) entry is the VLAN interface of this super
VLAN.
List of 1 outgoing interface: Outgoing interface list of the (S, G) entry.
71
