IDEC SmartAXIS Touch FT1A Series

SmartAXIS Touch User's Manual 29-17
1 Touch
29
SmartAXIS Specifications
■ FT1A-*14KA/SA
Unit: mm
<Cable Attached Dimensions>
Depending on the type of connection cable used the dimensions shown above will change.
The dimensions given here are intended for reference only.
77.0 65.5
116.0
4.0 54.0
(58.9)
104.5
50
15
30
20
