IDEC SmartAXIS Touch FT1A Series User Manual

3 Project Settings Dialog Box
3-26 SmartAXIS Touch User's Manual
System Area 3
This area is for changing the Touch internal clock data.
System Area 4
This area reads the Touch internal clock data in one minute intervals.
Address Bit Function Description
+4
0 to 7 Clock data Month Enter Month (01 to 12) as a 2 digit BCD.
8 to 15 Clock data Year Enter Year (00 to 99) as a 2 digit BCD.
+5
0 to 7 Clock data Hour Enter Hour (00 to 23) as a 2 digit BCD.
8 to 15 Clock data Day Enter Day (01 to 31) as a 2 digit BCD.
+6
0 to 7 Clock data Second Enter Second (00 to 59) as a 2 digit BCD.
8 to 15 Clock data Minute Enter Minute (00 to 59) as a 2 digit BCD.
+7
0 to 14 Reserved Enter 0 in the reserved area.
15 Update
Write 1 to this bit to write the entered data (address+4 to +6, bits
0 to 15) to the Touch internal clock data.
When the value of the update bit (address+7, bit 15) becomes 1, the clock data is updated as a whole.
Year, month, day, hour, minute, and second cannot be set individually.
Address Bit Function Description
+8
0 to 7 Clock data Month
These bits store the current Month (01 to 12) value as a 2 digit
BCD.
8 to 15 Clock data Year
These bits store the current Year (00 to 99) value as a 2 digit
BCD.
+9
0 to 7 Clock data Hour
These bits store the current Hour (00 to 23) value as a 2 digit
BCD.
8 to 15 Clock data Day
These bits store the current Day (01 to 31) value as a 2 digit
BCD.
+10
0 to 7 Reserved
8 to 15 Clock data Minute
These bits store the current Touch internal clock data Minute (00
to 59).
+11
0 to 3 Clock data Day of Week
These bits store the current Day of Week value as a 2 digit BCD.
00: Sunday
01: Monday
02: Tuesday
03: Wednesday
04: Thursday
05: Friday
06: Saturday
4 to 15 Reserved
