SmartAXIS Touch User's Manual 3-25
3 Project Settings Dialog Box
3
Project
System Area 2
This area stores Touch states and error information. These bits turn 0 immediately after power is turned on.
Address
Bit Function Description
+2
0 to 2 Reserved
3 Communication error
This bit changes to 1 when a communication error occurs in
communication with external device using Serial Interface 1
(SIO1).
4 Reserved
5 Arithmetic error
This bit changes to 1 when executing the following arithmetic
operations.
• A value other than 0 to 9 is used when the data type is BCD4
or BCD8
• Dividing by zero
• When there is an inconsistency in the bar chart maximum,
minimum, or origin setting, or the full range is 0
• When there is an inconsistency in the line chart maximum,
minimum, or origin setting, or the full range is 0
6 Device range error
This bit changes to 1 when writing a value to a device that falls
outside its range or when exceeding the restrictions on the
number of configured devices.
7 Clock IC error This bit changes to 1 when the Touch internal clock stops.
8, 9 Reserved
10 Script error
This bit changes to 1 when an error occurs during script
execution. Error details are stored in HMI Special Data Registers
LSD52 and LSD53. For details, refer to Chapter 20 “1.4 Script
Error of HMI Function” on page 20-4.
11 USB flash drive access error
If an error occurs when accessing an inserted USB flash drive,
the value of this bit becomes 1.
12, 13 Reserved
14 Backup data error
This bit changes to 1 when the backup battery is dead or low
and the data sampled by the log functions and the HMI Keep
Registers and HMI Keep Relays are cleared.
15 Reserved
+3
0
Numerical Input setting
complete
This bit changes to 1 when finished entering a numerical value
with the Numerical Input. Write 0 to Numerical Input setting
clear (address+1, bit 10) to clear this bit.
1
Numerical Input setting
cancel
This bit changes to 1 when entering a numerical value with the
Numerical Input was canceled. Write 0 to Numerical Input
setting clear (address+1, bit 10) to clear this bit.
2 Backlight auto off running
The value of this bit changes to 1 when Auto Backlight OFF is
configured and the backlight was turned off by this function. To
configure Auto Backlight OFF, select the Auto Backlight OFF
check box on the System tab in the Project Settings dialog box.
This bit automatically changes to 0 when the backlight turns on.
3 Reserved
4 Transferring recipe
This bit changes to 1 when transferring recipe data. This bit
automatically changes to 0 when the transfer is finished.
5
Character Input setting
complete
This bit changes to 1 when finished entering text with the
Character Input. Write 0 to Character Input setting clear
(address+1, bit 11) to clear this bit.
6 Character Input setting cancel
This bit changes to 1 when entering text with the Character
Input is canceled. Write 0 to Character Input setting clear
(address+1, bit 11) to clear this bit.
7 to 15 Reserved
To Next Page
