3 Project Settings Dialog Box
3-24 SmartAXIS Touch User's Manual
+1
2
Blink backlight
(0.5 sec. cycle)
This bit stores the screen blink state (0.5 sec. cycle). Write a value to
this bit to change the state. This bit is 0 immediately after the power
is turned on.
0: Do not blink
Stop blinking the screen and turn it on.
1: Blink
Blinks the screen in 0.5 second intervals.
When Blink backlight (1 sec. cycle) (address+1, bit 1) and Blink
backlight (0.5 sec. cycle) (address+1, bit 2) are both 1, the
screen blinks at one second intervals.
3 to 4 Backlight color
This bit stores the color of backlight. Write a value to this bit to
change the color.
Monochrome LCD models
00: Reserved
01: White
10: Red
11: Pink
Color LCD models
01: White
00, 10 and 11: Reserved
5Auto Backlight OFF
This bit stores whether or not the function to automatically turn off
the backlight is enabled when the Auto Backlight OFF check box is
selected in the Project Settings dialog box. Write a value to this bit to
change the state. This bit turns 0 immediately after power is turned
on.
0: Enabled
Automatically turns off the backlight when the Touch is unused
for an extended period of time.
1: Disabled
Does not automatically turn off the backlight when the Touch
is unused for an extended period of time. The backlight turns
on if the value changes to 1 when the backlight is off.
6Beep
This bit stores the beep state. Write a value to this bit to change the
state. This bit turns 0 immediately after power is turned on.
0: Stop
Stops continuous beeping.
1: Beep
Starts continuous beeping.
7 Screen display The function is the same as for Backlight (address+1, bit0)
8 Reserved
9 Clear error
Write 1 to this bit to clear the error information bit (System Area 2
address+2). This bit automatically changes to 0 when processing is
finished.
10
Numerical Input setting
clear
Write 1 to this bit to clear the Numerical Input setting complete bit
(System Area 2 address+3, bit 0) and the Numerical Input setting
cancel bit (System Area 2 address+3, bit 1). This bit automatically
changes to 0 when processing is finished.
11
Character Input setting
clear
Write 1 to this bit to clear the Character Input setting complete bit
(System Area 2 address+3, bit 5) and the Character Input setting
cancel bit (System Area 2 address+3, bit 6). This bit automatically
changes to 0 when processing is finished.
12 to 15 Reserved
