SmartAXIS Touch User’s Manual 15-5
1 Overview
15
Operation Log Function
8. Part Name: The part name for the pressed touch switch when the Press buttons event occurs.
9. Device Address: The destination device when the Write Data to any Devices event occurs.
When an indirect write is used, the device specified by the indirect value is recorded.
Example: When the device configured as the destination for the value 100 is LDR100 and the
indirect value is 3
10. Changed to: The result produced from the event that occurred. The recorded content varies based on the
event that occurred.
Switch to Base Screen: The screen type and number after switching.
Base n: Base Screen (n: screen number)
Example: Base 1
Change Users: The user name after the change.
Change Operation Modes: The operation mode after the change.
Run Mode: Run Mode
System Mode: System Mode
Monitor Mode: Monitor Mode
Write Data to any Devices: The value written to the device by pressing the touch switch. This value
is handled as BIN16 (+). For details, refer to Chapter 2 “1.2 Available
Data” on page 2-2.
The value written to the device is recorded as BIN16 (+) regardless of
the data type.
Example: When -10 (0xFFF6) is written to device D0
If the written value is 2 words (32 bits), each word is recorded (16 bits).
For the storage order for 32-bit device data, the upper word and lower
word are stored following the Storage Method of 32-bit Numerical
Data setting. Storage Method of 32-bit Numerical Data is
configured on the System tab in the Project Settings dialog box. For
details, refer to Chapter 3 “3.1 System Tab” on page 3-19.
Example: When Storage Method of 32-bit Numerical Data is from
Lower word and 12345678 (0xBC614E) is written to device
D0 with the data type BIN32 (+)
Event Name Part Name Details Changed to
Press buttons WordSwitch1 – –
Write Data to any Devices – LDR103 100
Event Name Part Name Details Changed to
Press buttons WordSwitch1 – –
Write Data to any Devices – D0 65526 (0xFFF6)
Event Name Part Name Details Changed to
Press buttons WordSwitch1 – –
Write Data to any Devices – D0 24910 (0x614E)
Write Data to any Devices – D1 188 (0xBC)
To Next Page
