SmartAXIS Touch User’s Manual 20-39
5 Script Coding Examples
20
Script
Script
Operation description
Converts the decimal numeric value in LDR200 to a string and stores it in order with LDR100 as the starting address.
Converting 1234 (when the data type is BIN16+)
Converting -12345 (when the data type is BIN16+/-)
Converting 1234567890 (when the data type is BIN32+)
Converting -1234567890 (when the data type is BIN32+/-)
■
Example 5.7.20 Convert decimal to string
DEC2ASCII([LDR 100], [LDR 200]);
• This function can be used with data types BIN16(+), BIN16(+/-), BIN32(+), BIN32(+/-), BCD4, and
BCD8.
• Only internal devices can be used.
• When using functions that handle strings, check the Storage Method of string data setting on the
System tab in the Project Settings dialog box. Depending on the setting, the upper and lower bytes are
stored in the reverse of the following explanation.
For details, refer to Chapter 3 “3.1 System Tab” on page 3-19.
• A NULL terminating character (0x00) is added to the end of the string.
Device
Stored value
Device Stored value Upper byte Lower byte
LDR200 1234 LDR100 '1' = 0x31 '2' = 0x32
LDR101 '3' = 0x33 '4' = 0x34
LDR102 0x00 0x00
Terminating character
Device
Stored value
Device Stored value Upper byte Lower byte
LDR200 -12345 LDR100 '-' = 0x2D '1' = 0x31
LDR101 '2' = 0x32 '3' = 0x33
LDR102 '4' = 0x34 '5' = 0x35
LDR103 0x00 0x00
Terminating character
Device
Stored value
Device Stored value Upper byte Lower byte
LDR200
1234567890
LDR100 '1' = 0x31 '2' = 0x32
LDR201 LDR101 '3' = 0x33 '4' = 0x34
LDR102 '5' = 0x35 '6' = 0x36
LDR103 '7' = 0x37 '8' = 0x38
LDR104 '9' = 0x39 '0' = 0x30
LDR105 0x00 0x00
Terminating character
Device
Stored value
Device Stored value Upper byte Lower byte
LDR200
-1234567890
LDR100 '-' = 0x2D '1' = 0x31
LDR201 LDR101 '2' = 0x32 '3' = 0x33
LDR102 '4' = 0x34 '5' = 0x35
LDR103 '6' = 0x36 '7' = 0x37
LDR104 '8' = 0x38 '9' = 0x39
LDR105 '0' = 0x30 0x00
Terminating character
