Dynamics 010: Stereo Noise Reduction
773
+: This is the default setting, for normal gate behavior. The
gate will open when the input is above the Threshold, and
close when the input falls below it.
–: This reverses the normal operation. The gate will close
when the input is above the Threshold, and open when the
input falls below it.
With –, the direction in which the modulation source opens
or closes the gate is reversed as well.
OUTPUT
This is the standard effects output section, with modulatable
control over wet/dry balance. For more information, see
“OUTPUT” on page 762.
010: Stereo Noise Reduction
This effect minimizes obtrusive noise by reducing the
volume when the signal is at a low level. You can use this if
a guitar or mic signal from the audio input contains noise.
ENVELOPE
Envelope Source [Input, FX Control 1, FX Control
2]
Selects the trigger source to use: the input signal, FX Control
Bus 1, or FX Control Bus 2. p.762.
Envelope Select [L/R Mix, Left, Right]
Selects whether the compressor is linked between left/right,
controlled only by the left signal, only by the right signal, or
independently for left and right. p.763.
Fx Control Trim [0…100]
This adjusts the level of the FX Control Bus inputs.
NOISE REDUCTION
Trigger Monitor [Check-box]
Switches between monitoring the effect output and the
trigger signal. p.768.
Threshold [dB] [–72.0…–22.0]
Sets the noise level
OUTPUT
This is the standard effects output section, with modulatable
control over wet/dry balance. For more information, see
“OUTPUT” on page 762.
On-screen graphic, 010 Stereo Noise Reduction
+
Left
Right
FX Control BUS 1
FX Control BUS 2
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
Envelope - Control
Trigger Monitor
Envelope Select
Envelope Source
This is a realtime indication of the control input signal level (Input), the
gain reduction produced by the control input signal (Gain Reduce),
and the output signal level (Output).
Noise Reduction reduces the noise level below the Threshold.
