Delay 080: Stereo/Cross Long Delay
835
080: Stereo/Cross Long Delay
This is a stereo delay with adjustable feedback routing, high
and low damping, modulatable feedback and input level, and
up to 2,730msec of delay time.
INPUT
Input Level Dmod [%] [+/–100]
Sets the modulation amount for the input level. For more
information, see “Input Level Dmod [%]” on page 823.
Source [Off…Tempo]
Selects the modulation source for the input level. For more
information, see “Source” on page 823.
DELAY
Stereo/Cross [Stereo, Cross]
This changes the feedback routing.
Stereo means that the left and right channels feed back into
themselves, preserving the stereo image.
Cross makes the left channel feeds back into the right, and
vice-versa.
L Delay Time [msec] [0.0…] 2730.0
Sets the delay time for the left channel.
R Delay Time [msec] [0.0…] 2730.0
Sets the delay time for the right channel.
L Feedback [+/–100]
Sets the feedback amount for the left channel.
R Feedback [+/–100]
Sets the feedback amount for the right channel.
Source [Off…Tempo]
Selects the modulation source of feedback amount.
L Amount [+/–100]
Sets the modulation amount of the left channel feedback.
R Amount [+/–100]
Sets the modulation amount of the right channel feedback.
High Damp [%] [0…100]
Sets the amount of high-frequency attenuation for the
feedback path.
Low Damp [%] [0…100]
This controls the low-frequency damping in the feedback
loop. See “Low Damp [%]” on page 833.
Spread [–50…+50]
This controls the stereo width of the effect. The stereo image
is widest with a value of 50, and narrows to mono with a
value of 0.
OUTPUT
This is the standard effects output section, with modulatable
control over wet/dry balance. For more information, see
“OUTPUT” on page 762.
081: Stereo Multitap Delay
The left and right Multitap Delays have two taps
respectively. Changing the routing of feedback and tap
output allows you to create various patterns of complex
effect sounds.
INPUT
Input Level Dmod [%] [+/–100]
Sets the modulation amount of the input level. See “Input
Level Dmod [%]” on page 823.
Source [Off…Tempo]
Selects the modulation source for the input level. p.823.
DELAY
Mode [Normal, Cross Feedback,
Cross Pan1, Cross Pan2]
This lets you alter the stereo image by switching the inputs
and feedback paths of the left and right delays, as shown in
the figure below. In order for this to be effective, the input
needs to be a true stereo signal.
Tap1 Time [msec] [0.0…1360.0]
Sets the Tap1 delay time.
Delay
Delay
Stereo/Cross
Left
Right
Feedback
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
Input Level D-mod
Input Level D-mod
High Damp Low Damp
High Damp
Low Damp
Spread
Stereo/Cross
Left
Right
Feedback
Spread
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
Input Level D-mod
Input Level D-mod
High Damp
Low Damp
High Damp
Low Damp
Delay
Delay
Feedback
Tap1 Level
Mode
Mode
(1)
(2)
(1)
(2)
Tap1=(1)
Tap2=(2)
Mode: Normal Mode: Cross Feedback
Mode: Cross Pan1 Mode: Cross Pan2
