Korg NAUTILUS Series

770
Threshold [dB] [–40…0]
Sets the overall level above which the limiter is applied.
Each band’s Offset parameter then works as an offset for this
parameter.
For more information, see “Threshold [dB]” on page 763.
Attack [1…100]
Sets the attack time. For more information, see “Attack
[msec]” on page 764.
Release [1…100]
Sets the release time. For more information, see “Release
[msec]” on page 764.
Gain Adjust [dB] [–Inf, –38…+24]
Sets the output gain. For more information, see “Gain Adjust
[dB]” on page 764.
Source [Off…Tempo]
Selects the modulation source for the output gain.
Amount [–63…+63]
Sets the modulation amount of the output gain.
LOW
Offset [dB] [–40…0]
This adjusts the Threshold level for the low range.
MID
Offset [dB] [–40…0]
This adjusts the Threshold level for the mid range.
HIGH
Offset [dB] [–40…0]
This adjusts the Threshold level for the high range.
OUTPUT
This is the standard effects output section, with modulatable
control over wet/dry balance. For more information, see
“OUTPUT” on page 762.
007: Stereo Multiband Limiter
This is a true-stereo multiband limiter. For more
information, see the mono version, “006: Multiband
Limiter,” above.
LIMITER
Ratio [1.0:1…50.0:1, Inf:1]
Sets the signal compression ratio. For more information, see
“Ratio” on page 763.
Threshold [dB] [–40…0]
Sets the level above which the compressor is applied. For
more information, see “Threshold [dB]” on page 763.
Attack [1…100]
Sets the attack time. For more information, see “Attack
[msec]” on page 764.
Release [1…100]
Sets the release time. p.764.
Gain Adjust [dB] [–Inf, –38…+24]
Sets the output gain. p.764.
Source [Off…Tempo]
Selects the modulation source for the output gain.
Amount [–63…+63]
Sets the modulation amount of the output gain.
LOW
Offset [dB] [–40…0]
This adjusts the Threshold level for the low range. For more
information, see “Threshold Offsets” on page 769.
MID
Offset [dB] [–40…0]
This adjusts the Threshold level for the mid range.
HIGH
Offset [dB] [–40…0]
This adjusts the Threshold level for the high range.
OUTPUT
This is the standard effects output section, with modulatable
control over wet/dry balance. For more information, see
“OUTPUT” on page 762.
Left
Right
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
Gain Adjust
Limiter
Limiter
Limiter
Envelope - Control
Envelope - Control
Envelope - Control
Gain Adjust
Limiter
Limiter
Low
Mid
High
Envelope - Control
Envelope - Control
Envelope - Control
Low
Mid
High
Oset
Band-Pass Filters
Limiter
