Korg NAUTILUS Series Parameter Guide

764
Attack [msec] [0.45…500.0]
This determines how quickly the compressor will take affect
after the signal crosses above the threshold.
Release [msec] [5…5000]
This controls how quickly the compressor will stop reducing
volume level after the signal falls below the threshold.
Lookahead [Check-box]
If this is on, the input signal to the compressor is delayed so
that the level will be detected from the trigger input before
the input signal is actually processed. This allows
compression to accurately follow changes in the trigger
input.
Gain Adjust [dB] [–Inf, –38…+24]
Sets the output gain. It’s often useful to increase the gain,
since compression causes the entire level to be reduced.
Source [Off…Tempo]
Selects the modulation source for the output gain.
Amount [–63…+63]
Sets the amount of output gain modulation.
OUTPUT
This is the standard effects output section, with modulatable
control over wet/dry balance. For more information, see
“OUTPUT” on page 762.
Soft Knee Width
Threshold
Soft Knee Width
Soft Knee Width = 0 dB
Soft Knee Width = 30 dB
Input Level
Output Level
Threshold
Ratio=Inf : 1
Attack=1
Release=1
Ratio=Inf : 1
Attack=100
Release=100
Dry
Wet
Wet
Release
Attack
Limiter - Attack / Release

Korg NAUTILUS Series Specifications

General

Sampling	Open Sampling System
MIDI	In, Out, Thru
Preset Combinations	384
Keyboard	61-key (NAUTILUS 61), 73-key (NAUTILUS 73), 88-key (NAUTILUS 88, RH3 weighted action)
Effects	12 Insert Effects; 2 Master Effects; 2 Total Effects
Sequencer	16-track MIDI Sequencer
Storage	Internal SSD (60 GB)
Audio Inputs	2 x 1/4"
Audio Outputs	Headphones
USB	Type A (host), Type B (device)
Weight	NAUTILUS 88: 23.1 kg
Display	8 inch TouchView™ GUI (800x600 pixels)
