NAUTILUS and MIDI CCs Responses to standard MIDI controllers
921
NAUTILUS and MIDI CCs
Responses to standard MIDI controllers
The following table shows the relationships between MIDI
CCs, physical controls on the NAUTILUS, and synthesis
and effects parameters.
CC# Name Range Notes
0 Bank select (MSB) 0…127 Bank Select message MSB *1
1 Modulation 1 0…127 Joystick +Y (forwards, away from the player)
2 Modulation 2 0…127 Joystick –Y (backwards, towards the player)
3 – – –
4 Foot Controller 0…127
AMS/Dmod source Foot Pedal.; may be assigned to the
Assignable Pedal
5 Portamento time 0…127 Portamento time
6 Data entry (MSB) 0…127 MSB of RPN and NRPN data *2
7 Volume 0…127 Main volume *3
8 Post Insert Effect pan 0…127 Pan after the Insert Effect (Post-IFX Pan)
9 – – –
10 Panpot 0…127 Pan
11 Expression 0…127 Scales main volume *3
12 Effect Control 1 0…127 AMS/Dmod source FX Control1
13 Effect Control 2 0…127 AMS/Dmod source FX Control2
14 ARP ON/OFF 0…63(Off ), 64…127(On)
Corresponds to on/off when CC#14 is assigned to the ARP
button
*6
15 DRUM ON/OFF Control 0…63(Off ), 64…127(On)
Corresponds to on/off when CC#15 is assigned to the DRUM
button
*6
16 Controller (CC#16) 0…127 For AMS, DMOD control
17 Controller (CC#17) 0…127 For AMS, DMOD control
18 Controller (CC#18) 0…127 For Alternate Modulation, Effect Dynamic Modulation control
19 Controller (CC#19) 0…127 For AMS, DMOD control
20 Knob Modulation 5 0…127
AMS/Dmod source Knob Mod.5;
may be assigned to RT control knobs 1…6
21 Knob Modulation 6 0…127
AMS/Dmod source Knob Mod.6;
may be assigned to RT control knobs 1…6
32 Bank select (LSB) 0…127 Bank Select message LSB *1
33…37 – – –
38 Data entry (LSB) 0…127 LSB of RPN or NRPN data *2
39…63 – – –
64 Damper 0…127 Damper (sustain pedal)
65 Portamento On/Off 0…63(Off ), 64…127(On) Turns portamento (glide) on/off
66 Sostenuto 0…63(Off), 64…127(On)
Sostenuto (holds only the notes sounding at the time that the
footswitch is turned on)
67 Soft 0…127 Soft pedal (reduces effective velocity)
68…69 – – –
70 Sustain level 0…127 Scales Sustain levels of the filter and amp EGs *4
71 Filter resonance level 0…127 Scales filter resonance amount *4
72 Release time 0…127 Scales Release times of the filter and amp EGs *4
73 Attack time 0…127 Scales Attack times of the filter and amp EGs *4
74 Filter cutoff frequency 0…127 Scales filter cutoff frequency (usually controls brightness) *4
