Appendices
920
Fixed assignments
The following physical controls have fixed assignments to
MIDI CCs:
PROGRAM mode
When one of the NAUTILUS’s controllers is operated, a
control change message will be transmitted on the global
MIDI channel (MIDI Channel GLOBAL 1–1a).
If one of the RT Control Knobs 1–6 or the assignable
pedal has been set to Master Volume, the universal
system exclusive message Master Volume will be
transmitted.
COMBINATION mode
When one of the NAUTILUS’s controllers is operated, a
control change message will be transmitted on the global
MIDI channel (MIDI Channel GLOBAL 1–1a).
Simultaneously, the message will also be transmitted on the
MIDI channel (MIDI Channel COMBINATION 2–1a) of
any timbre whose Status (COMBINATION 0–1b, 2–1a) is
EXT or EX2.
When one of the NAUTILUS’s controllers is operated, its
effect will apply to any timbre whose Status is INT and
whose MIDI Channel setting is either Gch or the same as
the global MIDI channel.
In the case of Master Volume, the universal exclusive
message Master Volume will be transmitted only on the
global MIDI channel.
You can make settings for MIDI Filter (COMBINATION
> MIDI FIlter/Zones– MIDI FIlter1(-3)) to enable or
disable control changes and controllers for each timbre.
When checked, the above operations will be enabled.
Effect dynamic modulation can be controlled when the Ch
(Channel) setting for IFX1–12, MFX1, 2, or TFX 1, 2 is
either set to Gch or to the same channel as the global MIDI
channel. (In the case of All Routed, control is possible on the
MIDI channel of any routed timbre.)
ARP modules A, B, C, and D can be controlled if the Input
Channel and Output Channel (COMBINATION 7–1c)
settings specified for each module are Gch or match the
global channel.
SEQUENCER mode
When one of the NAUTILUS’s controllers is operated, its
effect will apply to the MIDI track 1–16 that is selected by
Track Select (SEQUENCER 0–1a).
If the Status (SEQUENCER 2–1a) of the track selected by
Track Select is EXT, EX2, or Both, a control change
message will be transmitted on the MIDI channel specified
by MIDI Channel (SEQUENCER 2–1a).
If the Status is INT or Both, operating one of the
NAUTILUS’s controllers will affect only that MIDI track.
Simultaneously, the same effect will also apply to any MIDI
track with the same MIDI Channel setting.
In the case of Master Volume, the universal exclusive
message Master Volume will be transmitted.
You can make settings for MIDI Filter (SEQUENCER >
MIDI FIlter/Zones– MIDI FIlter1(-3)) to enable or
disable control changes and controllers for each track.
When checked, the operations effective for a Status of
INT or Both will be enabled. Tracks whose Status is
EXT, EX2, or Both will transmit control changes
regardless of this setting.
Effect dynamic modulation can be controlled when the Ch
(SEQUENCER 8–7a, 9–2a, 9–3, 9–4) setting for IFX1–12,
MFX1, 2, or TFX1, 2 matches the MIDI channel of the track
selected by Track Select. (In the case of All Routed, control
is possible on the MIDI channel of all routed tracks.)
If one of the NAUTILUS’s controllers is operated during
realtime recording, the corresponding or assigned control
change will be recorded.
SAMPLING mode
When one of the NAUTILUS’s controllers is operated, a
control change message will be transmitted on the global
MIDI channel (MIDI Channel GLOBAL 1–1a).
In the case of Master Volume, the universal exclusive
message Master Volume will be transmitted.
It is not possible to make AMS settings in SAMPLING
mode.
Joystick +Y Modulation 1 (CC#1)
Joystick -Y Modulation 2 (CC#2)
Joystick X Pitch Bend
Value Slider CC#18
RT Control Knob 1 Filter cutoff frequency (CC#74)
RT Control Knob 2 Filter resonance (CC#71)
RT Control Knob 3 Filter EG intensity (CC#79)
RT Control Knob 4 Release time (CC#72)
SW1 SW1 modulation On/Off (CC#80)
SW2 SW2 modulation On/Off (CC#81)
Ribbon Controller Ribbon controller (CC#16)
Damper pedal Damper (CC#64)
