Modulation and Pitch Shift 070: Pitch Shifter BPM
825
070: Pitch Shifter BPM
This pitch shifter enables you to set the delay time to match
the song tempo.
INPUT
Input Level Dmod [%] [+/–100]
Sets the modulation amount of the input level. See “Input
Level Dmod [%]” on page 823.
Source [Off…Tempo]
Selects the modulation source for the input level.
PITCH SHIFTER
Mode [Slow, Medium, Fast]
This controls whether the pitch shift will preserve tonal
quality but have a longer delay time (Slow), or be fast but
with lower quality (Fast). For details, see “Mode” on
page 823.
Pitch Shift [1/2 steps] [–24…+24]
Sets the pitch shift amount in steps of a semitone. p.823
Fine [cents] [+/–100]
Sets the pitch shift amount in steps of one cent. p.823
Source [Off…Tempo]
Selects the modulation source for both Pitch Shift and Fine.
Pitch Shift Amount [–24…+24]
Sets the modulation amount for Pitch Shift.
Fine Amount [+/–100]
Sets the modulation amount for Fine.
DELAY
BPM [MIDI, 40.00…300.00]
MIDI syncs to the system tempo; 40-240 sets the tempo
manually for this individual effect.
Time Over?> [---, OVER!]
The maximum delay time is 2,000msec. If the channel’s
combination of BPM, Base Note, and Times exceeds this
limit, the error message “OVER!” will appear. If this occurs,
change the delay time parameters so that this message no
longer appears.
Base Note [ … ]
This sets the basic delay length, relative to the BPM setting.
The values range from a 32nd note to a whole note,
including triplets.
Times [x1…x32]
This multiplies the length of the Base Note. For instance, if
the Base Note is set to a sixteenth note, and Times is set to 3,
result will be a dotted eighth note.
Feedback Position [Pre, Post]
Switches the feedback connection. p.824.
Feedback [+/–100]
Sets the feedback amount. p.824.
High Damp [%] [0…100]
Sets the amount of high-frequency attenuation for the
feedback path.
OUTPUT
This is the standard effects output section, with modulatable
control over wet/dry balance. For more information, see
“OUTPUT” on page 762.
BPM
BPM
Base Note x Times
Left
Right
Wet / Dry
Wet / Dry
Wet: Mono In - Mono Out / Dry: Stereo In - Stereo Out
Input Level
Input Level
+
High Damp
Delay
Feedback
Pitch Shifter
Feedback Position
Pre
Post
Tempo
