EXi: AL-1 Analog Synthesizer
180
AL-1: Tone Adjust
AL-1 Tone Adjust Default Settings
Tone Adjust provides an elegant physical interface to the
AL-1’s parameters. Most of the factory sounds use the
default layout, as shown above. You can also customize the
layout for individual sounds, if desired.
For more information about Tone Adjust, please see “0–9a:
Tone Adjust,” on page 29.
AL-1 Tone Adjust parameters
The AL-1 supports all of the Common Tone Adjust
parameters, as described under “0–9a: Tone Adjust,” on
page 29. It also adds a number of its own additional
parameters, which apply only to the AL-1.
Note that these additional parameters are separate for each
EXi, as opposed to being shared by both EXi in the Program.
All of the additional parameters are listed below. Each is
marked as either relative (meaning that it scales the existing
parameter value) or absolute (which over-writes the existing
value).
Oscillator 1
• Tune (absolute)
• Waveform (absolute)
• Morph (absolute)
• Morph AMS Intensity (absolute)
• Detune/Pulse Width (absolute)
• Detune/Pulse Width AMS Intensity (absolute)
Oscillator 2
Oscillator 2 has the same Tone Adjust parameters as
Oscillator 1, above.
Oscillators common
• Sync On/Off (absolute)
• FM Amount (absolute)
• FM AMS Intensity (absolute)
Buttons 1–5:
Mixer Mutes
OSC 1, OSC 2,
Sub OSC/Audio,
Ring Mod,
Noise
Oscillators 1 & 2
Width/Phase/
Detune
AMS Intensity
EG 1 (Filter)
ADSR
Amp EG ADSR
Filters A & B
EG Intensi
FM Amount Drive LFOs 1 & 2
Speed
Button 6:
Sync On/O
Buttons 7 & 8:
LFOs 1 & 2
Stop
