Delay 093: Stereo BPM Delay
847
093: Stereo BPM Delay
This stereo delay enables you to set the delay time to match
the song tempo. Fine adjustment lets you change the
rhythmic feel of the delays.
INPUT
Input Level Dmod [%] [+/–100]
Sets the modulation amount for the input level. For more
information, see “Input Level Dmod [%]” on page 823.
Source [Off…Tempo]
Selects the modulation source for the input level.
DELAY
BPM [MIDI, 40.00…300.00]
MIDI syncs to the system tempo; 40-240 sets the tempo
manually for this individual effect.
Time Over? L > [---, OVER!]
Time Over? R > [---, OVER!]
The maximum delay time is 1,360msec per channel (left and
right). If the channel’s combination of BPM, Base Note, and
Times exceeds this limit, the error message “OVER!” will
appear. If this occurs, change the delay time parameters so
that this message no longer appears.
L Delay Base Note [ … ]
This sets the basic length of the Left Delay, relative to the
BPM setting. The values range from a 32nd note to a whole
note, including triplets.
Times [x1…x32]
This multiplies the length of the Base Note. For instance, if
the Base Note is set to a sixteenth note, and Times is set to 3,
the delay length will be a dotted eighth note.
Adjust [%] [–2.50…+2.50]
This adjusts the left channel delay time by up to 2.5% in
either direction, for subtle control over the feel of the delay.
R Delay Base Note [ … ]
This sets the basic length of the Right Delay, relative to the
BPM setting.
Times [x1…x32]
This multiplies the length of the Right Delay’s Base Note.
Adjust [%] [–2.50…+2.50]
Fine-adjust the right channel delay time.
L Feedback [+/–100]
Sets the feedback amount for the left channel.
R Feedback [+/–100]
Sets the feedback amount for the right channel.
Source [Off…Tempo]
Selects the modulation source of feedback amount.
L Amount [+/–100]
Sets the modulation amount of the left channel feedback.
R Amount [+/–100]
Sets the modulation amount of the right channel feedback.
High Damp [%] [0…100]
Sets the amount of high-frequency attenuation for the
feedback path.
Low Damp [%] [0…100]
Sets the amount of low-frequency attenuation for the
feedback path.
OUTPUT
This is the standard effects output section, with modulatable
control over wet/dry balance. For more information, see
“OUTPUT” on page 762.
Left
Right
Feedback
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
Input Level D-mod
Input Level D-mod
High Damp Low Damp
High Damp
Low Damp
Tempo
BPM
BPM
Base Note x Times
Base Note x Times
Adjust [%]
Adjust [%]
Delay
Delay
