Korg NAUTILUS Series

848
094: Stereo BPM Long Delay
The stereo delay enables you to match the delay time with
the song tempo. You can set the delay time up to 2,730msec.
INPUT
Input Level Dmod [%] [+/–100]
Sets the modulation amount for the input level. For more
information, see “Input Level Dmod [%]” on page 823.
Source [Off…Tempo]
Selects the modulation source for the input level.
DELAY
BPM [MIDI, 40.00…300.00]
MIDI syncs to the system tempo; 40-240 sets the tempo
manually for this individual effect.
Time Over? L > [---, OVER!]
Time Over? R> [---, OVER!]
The maximum delay time is 2,730msec per channel (left and
right). If the channel’s combination of BPM, Base Note, and
Times exceeds this limit, the error message “OVER!” will
appear. If this occurs, change the delay time parameters so
that this message no longer appears.
L Delay Base Note [ …  ]
This sets the basic length of the Left Delay, relative to the
BPM setting. The values range from a 32nd note to a whole
note, including triplets.
Times [x1…x32]
This multiplies the length of the Base Note. For instance, if
the Base Note is set to a sixteenth note, and Times is set to 3,
the delay length will be a dotted eighth note.
Adjust [%] [–2.50…+2.50]
This adjusts the left channel delay time by up to 2.5% in
either direction, for subtle control over the feel of the delay.
R Delay Base Note [ …  ]
This sets the basic length of the Right Delay, relative to the
BPM setting.
Times [x1…x32]
This multiplies the length of the Right Delay’s Base Note.
Adjust [%] [–2.50…+2.50]
Fine-adjust the right channel delay time.
L Feedback [+/–100]
Sets the feedback amount for the left channel.
R Feedback [+/–100]
Sets the feedback amount for the right channel.
Source [Off…Tempo]
Selects the modulation source of feedback amount.
L Amount [+/–100]
Sets the modulation amount of the left channel feedback.
R Amount [+/–100]
Sets the modulation amount of the right channel feedback.
High Damp [%] [0…100]
Sets the damping amount in the high range. For more
information, see “High Damp [%]” on page 833.
Low Damp [%] [Korg0…100]
Sets the damping amount in the low range. For more
information, see “Low Damp [%]” on page 833.
OUTPUT
This is the standard effects output section, with modulatable
control over wet/dry balance. For more information, see
“OUTPUT” on page 762.
Left
Right
Feedback
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
Input Level D-mod
Input Level D-mod
High Damp Low Damp
High Damp
Low Damp
Tempo
BPM
BPM
Base Note x Times
Adjust [%]
Base Note x Times
Adjust [%]
Delay
Delay
