Delay 091: L/C/R BPM Delay
845
091: L/C/R BPM Delay
The L/C/R delay enables you to match the delay time with
the song tempo. You can also synchronize the delay time
with the arpeggiator or sequencer. If you program the tempo
before performance, you can achieve a delay effect that
synchronizes with the song in real-time. Delay time is set by
notes.
INPUT
Input Level Dmod [%] [+/–100]
Sets the modulation amount of the input level. p.823.
Source [Off…Tempo]
Selects the modulation source for the input level. p.823.
DELAY
BPM [MIDI, 40.00…300.00]
MIDI syncs to the system tempo; 40-240 sets the tempo
manually for this individual effect.
Time Over?>. [---, OVER!]
The maximum delay time is 2,730msec. If the combination
of BPM, Base Note, and Times exceeds this limit, the error
message “OVER!” appears in the display. If this occurs,
change the delay time parameters so that this message no
longer appears.
L Delay Base Note [ … ]
This sets the basic length of the Left Delay, relative to the
BPM setting. The values range from a 32nd note to a whole
note, including triplets.
Times [x1…x32]
This multiplies the length of the Base Note. For instance, if
the Base Note is set to a sixteenth note, and Times is set to 3,
the delay length will be a dotted eighth note.
Level [0…50]
Sets the output level of the Left Delay.
C Delay Base Note [ … ]
This sets the basic length of the Center Delay, relative to the
BPM setting.
Times [x1…x32]
This multiplies the length of the Center Delay’s Base Note.
Level [0…50]
Sets the output level of the Center Delay.
R Delay Base Note [ … ]
This sets the basic length of the Right Delay, relative to the
BPM setting.
Times [x1…x32]
This multiplies the length of the Right Delay’s Base Note.
Level [0…50]
Sets the output level of the Right Delay.
Feedback (C Delay) [+/–100]
Sets the amount of feedback from the Center Delay.
Source [Off…Tempo]
Selects the modulation source for the Center Delay
feedback.
Amount [+/–100]
Sets the modulation amount of the Center Delay feedback.
High Damp [%] [0…100]
Sets the amount of high-frequency attenuation for the
feedback path.
Low Damp [%] [0…100]
Sets the amount of low-frequency attenuation for the
feedback path.
Spread [0…50]
Sets the width of the stereo image of the effect sound. For
more information, see “Spread” on page 833.
OUTPUT
This is the standard effects output section, with modulatable
control over wet/dry balance. For more information, see
“OUTPUT” on page 762.
C Delay
Left
Right
Feedback
Spread
Wet / Dry
Wet / Dry
Wet: Mono In - Stereo Out / Dry: Stereo In -Stereo Out
Input Level D-mod
High Damp
Low Damp
L Delay
Input Level D-mod
+
Level
Level
Level
Tempo
BPM
BPM
Base Note x Times
Base Note x Times
Base Note x Times
R Delay
