CX-3: Tone Adjust 9–1: AMS Mixer
203
CX-3: Tone Adjust
CX-3 Tone Adjust Default Settings
Tone Adjust provides an elegant physical interface to the
CX-3’s parameters. Most of the factory sounds use the
default layout, as shown above.
You can also customize the layout for individual sounds, if
desired. For instance, most of the factory sounds use the
sliders for the upper drawbars; if you like, you can re-assign
them to the lower drawbars instead.
For more information about Tone Adjust, please see “0–9a:
Tone Adjust,” on page 29.
CX-3 Tone Adjust parameters
The CX-3 is substantially different from other EXi
instruments, so it does not support the Common Tone Adjust
parameters. Instead, it adds a number of its own, unique
parameters, as described below.
All of these parameter are absolute, which means that they
over-write the stored parameter values.
Note that these controls are separate for each EXi, as
opposed to being shared by both EXi in the Program.
Drawbars
• Upper Drawbars 1-9
• Lower Drawbars 1-9
• Upper EX Drawbars 1-4
• Lower EX Drawbars 1-4
• Noise level
• Leakage level
• Wheel Brake
• Overtone Level
• Key-On Click Level
Buttons 1–4:
Percussion On/O,
Perc. Level Soft/Loud,
Perc. Decay Slow/Fast,
Perc. Harmonic 2nd/3rd
Amp Gain
Expression Level
Overtone Level
Key-On Click Level
EQ Bass EQ Mid EQ TrebleVibrato/Chorus Type
Upper
Drawbars 1–9
Buttons 5–6:
Upper V/C On/O,
Lower V/C On/O
Button 7:
Wheel Brake On/O
Button 8:
Split On/O
