860
Mono-Mono Serial
109: P4EQ - Exciter through 140: Reverb - Gate provide
serial chains of mono effects. These include various
combinations of EQ, Compressor, Limiter, Exciter,
Overdrive, Wah, Chorus/Flanger, Phaser, Multitap Delay,
Gate, and Reverb, as described below.
PARAMETRIC EQ
For a description of the on-screen EQ graphic, see “011:
Stereo Parametric 4EQ” on page 774.
Trim [0…100]
Sets the parametric EQ input level.
Band1 Fc [Hz] [20…1.00k]
Sets the center frequency of Band 1.
Q [0.5…10.0]
Sets the bandwidth of Band 1. For more information, please
see “Q” on page 774.
Gain [dB] [–18…+18]
Sets the gain of Band 1.
Band2 Fc [Hz] [50…5.00k]
Sets the center frequency of Band 2.
Q [0.5…10.0]
Sets the bandwidth of Band 2.
Gain [dB] [–18…+18]
Sets the gain of Band 2.
Band3 Fc [Hz] [300…10.00k]
Sets the center frequency of Band 3.
Q [0.5…10.0]
Sets the bandwidth of Band 3.
Gain [dB] [–18…+18]
Sets the gain of Band 3.
Band4 Fc [Hz] [500…20.00k]
Sets the center frequency of Band 4.
Q [0.5…10.0]
Sets the bandwidth of Band 4.
Gain [dB] [–18…+18]
Sets the gain of Band 4.
EXCITER
Emphasis Frequency [0…70]
Sets the frequency range to be emphasized. For more
information, see “Emphasis Frequency” on page 777.
Exciter Blend [+/–100]
Sets the intensity (depth) of the Exciter effect. For more
information, see “Blend” on page 777.
MULTITAP DELAY
Tap1 Time [msec] [0.0…1360.0]
Sets the Tap1 delay time.
Tap2 Time [msec] [0.0…1360.0]
Sets the Tap2 delay time.
Tap1 Level [0…100]
Sets the Tap1 output level. For more information, see “Tap1
Level” on page 836.
Feedback (Tap2) [+/–100]
Sets the Tap2 feedback amount.
High Damp [%] [0…100]
Sets the amount of high-frequency attenuation.
Wet/Dry [Dry, 1:99…99:1, Wet]
Sets the multitap delay effect balance. For more information,
see “Pan” on page 827.
Source [Off…Tempo]
Selects the Wet/Dry modulation source for the multitap
delay.
Amount [+/–100]
Sets the Wet/Dry modulation amount for the multitap delay.
COMPRESSOR
For details on the Compressor graphics, see “001: Stereo
Dyna Compressor” on page 761.
Sensitivity [1…100]
Sets the sensitivity. For more information, see “Sensitivity”
on page 761.
Attack [1…100]
Sets the attack level. For more information, see “Attack” on
page 762.
Output Level [0…100]
Sets the compressor output level. For more information, see
“OUTPUT” on page 762.
LIMITER
For details on the Limiter graphics, see “005: Stereo
Limiter” on page 768.
Ratio [1.0:1…50.0:1, Inf:1]
Sets the signal compression ratio. For more information, see
“Ratio” on page 763.
Threshold [dB] [–40…0]
Sets the level above which the compressor is applied. For
more information, see “Threshold [dB]” on page 763.
Attack [1…100]
Sets the attack time. For more information, see “Attack
[msec]” on page 764.
