Korg NAUTILUS Series - 4-6: Amp2 Mod; 4-7: Amp2 EG; 4-9: Eq

PROGRAM mode: HD-1
82
4–6: Amp2 Mod.
This page controls Oscillator 2’s amp modulation. It is
available only when the Oscillator Mode is set to Double; if
not, the page will be grayed out.
The parameters are identical to those for Oscillator 1, as
described under “4–2: Amp1 Mod.,” on page 76.
4–7: Amp2 EG
This page controls Oscillator 2’s amp EG. It is available only
when the Oscillator Mode is set to Double; if not, the page
will be grayed out.
The parameters are identical to those for Oscillator 1, as
described under “4–3: Amp1 EG,” on page 79.
4–9: EQ
This three-band EQ, with sweepable mid, is shared by both
of the Program’s oscillators. The Drum Track has its own
EQ: for more information, see “EQ” on page 17.
In Combis and Sequences, each timbre and track has its own
individual EQ. You can import the Program’s EQ settings
into Tracks and Timbres by using the Combi and Sequence
“Auto-Load Program EQ” options.
4–9a: 3 Band Parametric EQ
Bypass [On, Off]
When Bypass is checked, all of the EQ will be disabled,
including the Input Trim.
Bypass can be convenient for comparing the results of the
EQ with the original signal.
Input Trim [00…99]
This controls the volume level going into the EQ.
High settings of the Low, Mid, and High Gain controls can
cause substantial increases in the overall level. You can
compensate for this by turning down the input trim.
Low Gain [–18.0…+18.0dB]
This controls the gain of the 80Hz Low Shelf EQ, in
increments of 0.5dB.
Mid Frequency [100Hz…10.00kHz]
This sets the center frequency for the Mid sweep EQ.
Mid Gain [–18.0…+18.0dB]
This controls the gain of the Mid Sweep EQ, in increments
of 0.5dB.
High Gain [–18.0…+18.0dB]
This controls the gain of the 10kHz High Shelf EQ, in
increments of 0.5dB.
v 4–9: Page Menu Commands
• Compare →p.112
• Write Program →p.112
• Exclusive Solo →p.113
• Copy Oscillator →p.119
• Swap Oscillator →p.119
• PAGE →p.126
•MODE →p.126
4–9PMC
4–9a
