824
DELAY
Delay Time [msec] [0…2000]
Sets the delay time.
Feedback Position [Pre, Post]
Pre feeds the delay back through the pitch shifter. Each time
the feedback repeats, the pitch will get increasingly lower or
higher.
Post means that the feedback does not go through the pitch
shifter, so that the pitch stays the same through successive
repeats.
Feedback [+/–100]
Sets the feedback amount.
High Damp [%] [0…100]
Sets the amount of high-frequency attenuation for the
feedback path.
OUTPUT
This is the standard effects output section, with modulatable
control over wet/dry balance. For more information, see
“OUTPUT” on page 762.
069: Stereo Pitch Shifter
This is a stereo pitch shifter. The pitch shift amount for the
left and right channels can be reversed from each other.
INPUT
Input Level Dmod [%] [+/–100]
Sets the modulation amount of the input level. See “Input
Level Dmod [%]” on page 823.
Source [Off…Tempo]
Selects the modulation source for the input level.
PITCH SHIFTER
Mode [Slow, Medium, Fast]
This controls whether the pitch shift will preserve tonal
quality but have a longer delay time (Slow), or be fast but
with lower quality (Fast). For details, see “Mode” on
page 823.
L/R Pitch [Normal, Up/Down]
Determines whether or not the L/R pitch shift amount is
inverted.
Normal: The pitches of the left and right channels shift
together.
Up/Down: the pitch shift amount for the right channel will
be reversed. If the pitch shift amount is positive, the pitch of
the left channel is raised, and the pitch of the right channel is
lowered.
Pitch Shift [1/2 steps] [–24…+24]
This sets the basic amount of pitch shifting, in semitones.
You can also make precise adjustments using Fine [cents],
below.
Fine [cents] [+/–100]
This adjusts the pitch shift in cents (1/100 of a semitone).
Source [Off…Tempo]
This selects the modulation source for Pitch Shift. As with
Pitch Shift itself, you can set the amount of modulation in
both semitones and cents.
Pitch Shift Amount [–24…+24]
This sets the basic amount of modulation, in semitones. You
can also make precise adjustments using Fine Amount,
below.
Fine Amount [+/–100]
This adjusts the amount of modulation in cents (1/100 of a
semitone).
DELAY
L Delay Time [msec] [0…2000]
Sets the delay time for the left channel.
R Delay Time [msec] [0…2000]
Sets the delay time for the right channel.
Feedback Position [Pre, Post]
Pre feeds the delay back through the pitch shifter. Each time
the feedback repeats, the pitch will get increasingly lower or
higher.
Post means that the feedback does not go through the pitch
shifter, so that the pitch stays the same through successive
repeats.
Feedback [+/–100]
Sets the feedback amount.
High Damp [%] [0…100]
Sets the amount of high-frequency attenuation for the
feedback path.
Spread [+/–100]
Sets the width of the stereo image of the effect sound. See
“Spread” on page 833.
OUTPUT
This is the standard effects output section, with modulatable
control over wet/dry balance. For more information, see
“OUTPUT” on page 762.
Left
Right
Feedback
Spread
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
High Damp
High Damp
Input Level
Input Level
Feedback Position
Pre
Pre
Post
Post
Delay
Pitch Shifter
Delay
Pitch Shifter
