EXi: MOD-7 Waveshaping VPM Synthesizer
336
PROGRAM > MOD-7: Filter
6–1: Basic
Overview
The MOD-7 includes dual multimode resonant filters,
including Korg’s Multifilter. These filters are almost
identical to those of the AL-1, except for the following:
• There is no Trim parameter.(This was unnecessary even
in the AL-1, since the filter will not clip internally.)
Output volume is still available and modulatable.
• The patch panel allows individual access to Filters A and
B, and so the Routing parameter provides only
Parallel
and 4-Pole modes. You can create serial routing using
the patch panel, if desired.
• Similarly, since Filters A and B have independent
outputs which can be routed separately to the Output
Mixer, there are no filter-specific Pan or Pan AMS
controls. The Output Mixer supports modulatable Pan for
all 6 inputs.
For detailed descriptions of the filter parameters, see “5–1:
Basic” on page 154.
For information about using the filters in the MOD-7,
including hands-on tutorials, see “Filtered VPM” on
page 304.
Filters and the Analog parameter
When the Oscillator Main page Analog parameter is greater
than 0, Filters A and B each get a different random detune
value (including when Link is set to On).
If you want the two filters to be perfectly in tune, turn
Analog to 0.
6–2: Multi Filter
The Multi Filter is identical to that of the AL-1. For detailed
information, see “5–2: Multi Filter” on page 157.
6–3: Filter Mod.
The Filter Modulation page is almost identical to that of the
AL-1. For detailed information, see “5–3: Filter Mod.” on
page 158.
There is one exception: in the Filter A and B EG Select
parameters, you can select any of the MOD-7 envelopes:
EG1…EG9, plus the Amp EG.
6–4: Filter LFO Mod.
The Filter LFO Mod page is identical to that of the AL-1.
For detailed information, see “5–4: Filter LFO Mod.” on
page 161.
