Leica Cyclone - Page 246

18 - 32 Module 4.1 – Texture Mapping Organization/Visualization Pointcloud
• Select
SelectSelect
Select all the Cube-Images and click Open
OpenOpen
Open
Figure 33
2.3 Create the point cloud object to texture
Texture mapping is done by object so you have to merge separate Clouds together by unifying or
merging the point clouds you want to apply the texture to.
• Open the ModelSpaceView warehouse
• Change to Top View
Top ViewTop View
Top View
Figure 34
