5.DefineSearchRectangle(Definebycornerpoints)
[Ifyouwouldprefernottodefinethesearchrectangledimensionsusing
themajorandminoraxis,therectanglecanbedefinedbysettingthe
coordinatesofeachcornerpointinstead]:
i.Enterthecoordinatesofeachcornerpoint1–4.
Note:
•Thecornercoordinatesneedtoformarectangle .Ifthecoordinatesare
notsuitablethenyouwillnotbeabletocreatethesearchroute.
•TheCSPmustbeononeofthesidesofthesearchpattern.
•ForaCreepingLinesearchpatterntheCSPmustbelocatedalongone
ofthelongersides.
•ForaParallelLinesearchpatterntheCSPmustbelocatedalongone
oftheshortersides.
•TheCSPmustbeonabearingofbetween85°to95°(i.e.rightangle±
5°)fromthepreviousside.
•TheCSPshouldbehalfatrackwidthfromthecornerpoint.
