FromtheDashboardapp
’s[Pages]settingsmenu[Menu>Settings>Pages]:
1.Select[Importcustompages].
2.Select[Yes]toconfirmimport.
3.Browseyourmemorycardforthecorrectconfigurationfileforthedisplay.
4.Selecttheconfigurationfile.
Thedigitalswitchingpagesandconfigurationwillbeimported.
Circuitssettingsmenu
TheCircuitssettingsmenuisusedtoseetrippedcircuitsrelatedto3rdparty
digitalswitchingconfigurations.
Unitssettingsmenu
TheUnits[]menuisusedtospecifyyourpreferredunitsofmeasurefor
datareadings.TheUnitsmenucanbeaccessedfromtheHomescreen:
[Homescreen>Settings>Units]orfromtheDashboardapp:[Menu>Settings
>Units].
Units
Measurement
Units
[Distanceunits]•[NM&ft]—Nauticalmiles&Feet
•[NM&m]—Nauticalmiles&
Meters
•[mi&ft]—Miles&Feet
•[km&m]—KilometersandMeters
•[NM&yd]—Nauticalmiles&
Y
ards
[Speedunits]•[K ts]—Knots
•[MPH]—Mileperhour
•[KPH]—Kilometersperhour
[Depthunits]•[Meters]—m
•[Feet]—ft
•[Fathoms]—Fm
Measurement
Units
[T
emperatureunits]•[Celsius]—C
•[Fahrenheit]—F
[Dateformat]
•MM:DD:YYYY
•DD:MM:YYYY
•MM:DD:YY
•DD:MM:YY
[Lat/Longformat]
•DD°MM’.MMM
•DD:MM:SS
•DD:MM:SS.S
•DD:MM.MMM
•DD°MM’SS
•DD°MM.MMM’
[Volumeunits]•[USGallons]—Gsl
•[ImperialGallons]—Gal
•[Liters]—Ltr
[Economyunits]
•DistanceperVolume
•VolumeperDistance
•Litersper100km
[Windspeedunits]•[Knots]—kts
•[MetersperSecond]—m/s
[Pressureunits]•[Bar]
•[PSI]
•[Kilopascals]—KP
a
[Timeformat]•12hr
•24hr
Dashboardapp
345

Raymarine LIGHTHOUSE 4 Specifications

General

Operating System	LightHouse 4
Touchscreen	Yes
Connectivity	NMEA2000, Ethernet, Wi-Fi
Chart Compatibility	Navionics, C-MAP
Display Size	Varies by model (e.g., 7", 9", 12", 16")
Display Resolution	Varies by model
Networking	Ethernet, Wi-Fi
GPS	Built-in
Radar Support	Yes, compatible with Raymarine radars
Sonar Support	Yes
Autopilot Integration	Yes, compatible with Raymarine autopilot systems
Weather Data	Yes, via internet
Software Updates	Via Wi-Fi
