Raymarine LIGHTHOUSE 4 - Transducer Settings Menu; Sounder Settings Menu

19
.15Transducersettingsmenu
SettingOptions
[T
ransducer]
AllowsselectionofSonartransducer.
Listofavailabletransducers.
[Displaydepthas]
Determinesthepositionfromwheredepth
readingsaretak
enfrom.
•Belowkeel
•Belowwaterline
•Belowtransducer
[Speedtransducer]
AllowsselectionofSpeedtransducer.
Listofavailabletransducers.
[Calibratespeed]
Allowsyoutoenteranoffsetbetweenactual
measuredspeedandthecurrentspeed
displayedbyyourtransducer .
Offsetvalue.
[Enabletemperaturesensor]
Enablesanddisablestheselected
transducer’stemperaturesensor.
•On
•Off
[Calibratetemp]
Allowsyoutoenteranoffsetbetween
actualmeasuredwatertemperatureand
thecurrenttemperaturedisplayedbyyour
transducer .
Offsetvalue.
19 .16Soundersettingsmenu
SettingOptions
[Soundername]
Allowsyoutorenameyoursonarmodule .
Onscreenkeyboard.
[Pingenable]
Enablesanddisablestransducerping.
•On
•Off
SettingOptions
[Pingratelimit]
Allowsyoutorestrictthetransducer’
s
maximumpingratetosuitcurrent
conditions.
•1to100
[P
owermode]
Adjuststhetransducer’ssignalstrength.In
[Auto]thesonarmodulewillautomatically
determinetheoptimalpowerbasedon
currentdepth,speedandbottomsignal.In
[Manual]youcanadjustthepowertothe
desiredlevel.
•1to100
[Pingrate]
Hyperpingshouldbeusedatspeedsofup
to40knotsinshallowerwaters(6metres
orless).Whenthedepthreaches6metres
orabovethepingratewillautomatically
reducetonormaluntildepthconditionsare
met.
•Normal
•Hyper
[Dualchannelpingmode]
Onsonarmodulesthatoffersimultaneous
dualchanneloperation,suchastheCP570,
Thepingmodecanbechanged.
[Auto]theFishfinderappwillselectthebest
modechosenbasedonrangesettings.
[Independentpings]maximizespingrate
butmayintroduceinterference.
[Simultaneouspings]reducedpingrateand
reduceschanceofinterference.
•Auto
•Independentpings
•Simultaneouspings
[Tunefrequency]
Enablesmanualtuningofnon-CHIRPsingle
frequencysonarchannels.
Theadjustmentrangeisdeterminedbythe
transducer/sonarmodule.
•Supportedfrequencies
Fishfinderapp
273
