Raymarine LIGHTHOUSE 4 User Manual

8.4PilotV
ersionkeypadLEDstatus(Axiom®2
Proonly)
ThePilotVersionlowerkeypadonanAxiom®2Prodisplayincludesan
AutopilotstatusLED.
LEDindicationS
tatusandrequiredaction
Solidgreen=A
utopilotactive/on.
Off=Autopilotinstandby.
Flashingred=Autopilotcalibrating,
Autopiloterror.
8.5Pilotpop-up
Duringactivenavigation,whenyoureachyourcurrentdestinationthePilot
pop-upisdisplayed.
Goto
WhenperformingaGotothePilotpop-upprovidesoptionstodisengagethe
autopilotortomaintainthecurrentcourseinL ockedheadingmode.
Follow
WhenfollowingaR
outethePilotpop-upprovidesoptionstomakethe
requiredturntothenextwaypoint,disengagetheautopilotortomaintainthe
currentcourseinLockedheadingmode.
8.6AutopilotControl—Pilotset-upmenu
MenuitemanddescriptionOptions
[Vesselhulltype]
Selectingthehulltypethatistheclosestmatchforyour
vesselprovidesoptimumsteeringperformance.
•Sail
•Sail(slowturn)
•Sail
Catamaran
•Power
•Power(slow
turn)
•Power(fast
turn)
[Drivetype]
Selectingthedrivetypethatmatchesyourvessel’s
drivewillprovideoptimumdriveperformance.
Listofdrives
compatiblewith
yourACU.
[Compassoffset]
AdjusttheCompassoffsetsothatyourautopilot’s
headingmatchestheship’scompass.
Thedisplayofautopilotheadingdatarequiresasecond
networkedMFDorpilotcontroller.
Compassoffsetwillbeadjustedautomaticallyduring
theAligncompasstoGPSprocedure.
•-10°to+10°
•0°(default)
A utopilotintegration
125
