–Catamaran(leeway10°–20°)
Note:Ifyouselectaboattypeotherthanonewithstatedleeway
anglesthennoleewaycorrectionwillbeappliedinthecalculations.
•[Displaylaylinesonthischart]—Enablesanddisablesdisplayoflaylines
thecurrentChartappinstance
.
•[Adjustfortides]—Whenenabledlaylinecalculationswilltakeintoaccount
tidalflow.
Polarlaylines
Thefollowingoptionsareavailableforpolarlaylines:
•[Sailperformance]—Usethisoptiontoswitchtousingspecifiedangles
[Fix edangles]ortodisablelaylines[Notset].
•[Polar]—Browsethelisttofindtheboatmodelthatmostcloselymatches
yourownboat.Ifyourboatisnotlisted,orifyouhavepolardatayouwould
likeincluded,pleasesendanemailtopolars@raymarine.com.
•[Boattype]—Selectingtheappropriateboattypewillprovidemore
accurateleewaycalculations.Onlyselectoneofthefollowingboattypes:
–Sailcruiser(leeway5°–10°)
–Racesail(leeway(3°–5°)
–Catamaran(leeway10°–20°)
Note:Ifyouselectaboattypeotherthanonewithstatedleeway
anglesthennoleewaycorrectionwillbeappliedinthecalculations.
•[Displaylaylinesonthischart]—Enablesanddisablesdisplayoflaylines
thecurrentChartappinstance
.
•[Adjustfortides]—Whenenabledlaylinecalculationswilltakeintoaccount
tidalflow.
Windshiftdata
AsTrueWindDirection(TWD)isconstantlychanging,thepositionofthe
laylineschangesovertime.Thesechangesareshownaslightercolored
shadedtriangleswhichrepresentthevariationofTWDoveraspecifiedtime
period.
•WithTWDholdingatthehighendofitsrangeofvariation,thevesselcan
tacktostarboardandwilllaythewindwardorleewardmarkasitenters
theshadedarea.However,ifTWDshiftsbacktowardsthelowerendofits
rangeofvariation,thevesselwillfallshortofthelaylineandmayhaveto
performextratackstoreachthewaypoint.
•WithTWDholdingatthelowendofitsrangeofvariation,thevesselcan
tacktostarboardandwillonlylaythewindwardorleewardmarkwhenit
reachestheendoftheshadedarea.However,ifTWDshiftsbacktowards
thehighendofitsrangeofvariation,thevesselwilloverstandthewindward
orleewardmarkandmayneedtotravelfarthertoreachthewaypoint.
•Dependingonthesituation,thenormalcourseofactionwouldbetotack
whenthevesselishalfwaythroughtheshadedarea.Howeverthismay
notbetheshortestorquickestroute.
222

Raymarine LIGHTHOUSE 4 Specifications

General

Operating System	LightHouse 4
Touchscreen	Yes
Connectivity	NMEA2000, Ethernet, Wi-Fi
Chart Compatibility	Navionics, C-MAP
Display Size	Varies by model (e.g., 7", 9", 12", 16")
Display Resolution	Varies by model
Networking	Ethernet, Wi-Fi
GPS	Built-in
Radar Support	Yes, compatible with Raymarine radars
Sonar Support	Yes
Autopilot Integration	Yes, compatible with Raymarine autopilot systems
Weather Data	Yes, via internet
Software Updates	Via Wi-Fi
