[R
otation]
TheRotationslidercontrolisusedtoadjusttheUAV’sdirectionof
rotationandrotationspeed.Withthecontrolontheslidercenter
linetheUAVwillmaintainpositioninrelationtoyourvessel.
MovingthesliderrightoftheslidercenterlinerotatestheUAV
counter-clockwiseandmovingtheslidercontroltotheleftofthe
centerlinerotatestheUAVclockwise.Thefartherleftorrightthe
slidercontrolissetthefastertherotationspeedwillbe.
5
[Virtualjoystick]
InFishOn/Circlememodetherightvirtualjoystickprovides
[Forward]and[Backwards]controlstoadjusttheU
AV’sheight
fromyourvessel.
Note:
DuringyourinitialMFDconfigurationtheboating[Activity]youselectedwill
determinewhetherthefunctionislabelled[Fishon]or[Circleme].IfFishing
(freshwater),Fishing(saltwater)orR etail/demonstrationisselectedthenthe
functionislabelled[Fishon],otherwisethefunctionislabelled[Circleme].
29
.14UAVChartintegration
WhenacompatibleUAVwithaGNSS(GPS)positionfixisconnectedto
yourMFD,aUAViconrepresentingthepositionoftheUAVisdisplayed
intheChartapp.
1
[UAVCOG]
ThedirectionoftheBluelineindicatestheUAV’scurrentCourse
OverGround(COG).ThelengthofthelineindicatestheUAV’s
predictedpositionwhenthespecifiedvectorReferenceperiod
haspassed.
TheVectorReferenceperiodcanbeadjustedfromthevessel
icon’scontextmenu.
2[UAVIcon]
DisplayedwhentheUAVoptionisenabledintheChartapp
settings,andyourUAVhasaGNSS(GPS)positionfix.
3[Cameraheading]
TheBlackCameraheadingarrowisfixedtoprovidean
indicationofthedirectiontheUAV’scameraispointingtowards.
4
[Linetovessel]
TheY
ellowdottedlinerepresentstheangleoftheUAV’s
positionrelativetoyourvessel.
U AV(UnmannedAerialVehicle)app
427

Raymarine LIGHTHOUSE 4 Specifications

General

Operating System	LightHouse 4
Touchscreen	Yes
Connectivity	NMEA2000, Ethernet, Wi-Fi
Chart Compatibility	Navionics, C-MAP
Display Size	Varies by model (e.g., 7", 9", 12", 16")
Display Resolution	Varies by model
Networking	Ethernet, Wi-Fi
GPS	Built-in
Radar Support	Yes, compatible with Raymarine radars
Sonar Support	Yes
Autopilot Integration	Yes, compatible with Raymarine autopilot systems
Weather Data	Yes, via internet
Software Updates	Via Wi-Fi
