theA
CCESSORYconnectiontoadashboardorbulkhead,tomakethe
connectionmoreaccessible.AUSB“MicroB”toUSB“A ”cablecanthenbe
usedtoconnecttheprimarycontrollertothedisplay,asshownbelow.
Note:
•TheRCR-SDUSBandRCR-1C
ANNOTbeusedtoconnectyourUAVto
thedisplay.
•TheUAVcanonlybecontrolledbythedisplaythattheprimarycontroller
isconnectedto.
•EnsurethattheUSBconnectiontoyourdisplayissecureandprotected
againstwateringress.
29
.5UAVprecautions
OperatingyourUAVoverwaterandlaunchingandretrievingyourUAVona
vesselcanbeasignificantlydifferentexperiencethanwhenonland.
Thefollowingprecautionsshouldbefollowed:
•Y ouwillneedtobeanexperienced,competentpilotaslaunchingand
retrievingtheUAVonavesselismoredifficultduetoconfinedspaceand
vesselmovement/drift.
•OnlylaunchyourUAVincalmwindandtideconditions.Whenattempting
tolaunchorretrieveyourUAVyourvesselshouldbetravellingatless
than1knotandyourcaptainshouldbereadyatthehelmtobackdownor
maneuverthevesseltoavoidaccidentalcollisions
•MaintainawarenessofyourUAV’sbatterystatus,remainingflighttime,
distancefromyourvesselandWindandTideconditions.AUAVflying
againstthewindwillconsumebatterypowermorerapidlythanwhenflying
downwindorincalmconditions.Alwaysbudgetsufficientpowerreserves
toensurethesafereturnandretrievalofyourUAV.
•MaintainapermanentwatchofyourUAVwhileinflight.TheUAVpilot
orcompetentobservermustmaintainawarenessofsurroundingairand
marinetrafficwhiletheUAVisinflight.Thepilotmustremainreadyto
takecontroloftheUAVandmanuallyflyittoavoidinterferingwithother
vesselsoraircraft.
•WhileyourUAV’scontrollerisconnectedtoyourMFDitshouldbe
positionedsothatitmaintainslineofsightwithyourairborneUAV.Ifthe
controllerisnothandheldthenitmustbesecuredtopreventitbecoming
disconnectedfromyourMFDandtopreventunintentionalbuttonpresses.
No-flyzones
ItisillegaltoflyyourUAVinno-flyzones.Noflyzonesinclude:
•Airports
•Airfields
•Countryborders
•Sensitiveinstitutions
422

Raymarine LIGHTHOUSE 4 Specifications

General

Operating System	LightHouse 4
Touchscreen	Yes
Connectivity	NMEA2000, Ethernet, Wi-Fi
Chart Compatibility	Navionics, C-MAP
Display Size	Varies by model (e.g., 7", 9", 12", 16")
Display Resolution	Varies by model
Networking	Ethernet, Wi-Fi
GPS	Built-in
Radar Support	Yes, compatible with Raymarine radars
Sonar Support	Yes
Autopilot Integration	Yes, compatible with Raymarine autopilot systems
Weather Data	Yes, via internet
Software Updates	Via Wi-Fi
