Wiring Diagrams 10-3
61 3 H-143 Connects the Engine Control Board and LV Harness.
120 3 G-137 Connects the Engine Control and Image Processor Boards.
132 1 H-109 Connects the Tray 1 Feed Solenoid and FRONT/DUP Harness.
133 1 D-108 Connects the Duplex Jam Sensor and FRONT/DUP Harness.
134 1 F-106 Connects the Full Stack Sensor and FRONT/DUP Harness.
135 1 E-109 Connects Tray 1 No Paper Sensor and FRONT/DUP Harness.
136 2 D-122 Connects the CTD (ADC) Sensor and FSR/ADC Harness.
137 3 B-137 Connects the Wire Assy Regi to the Registration Roller Assy.
138 3 B-136 Connects the Wire Assembly BTR to the Transfer Roller.
139 3 E-133 Connects the HVPS and Wire Assembly BTR.
140 3 E-133 Connects the HVPS and Wire Assembly Regi.
141 3 E-135 Connects the HVPS and HVPS Harness.
142 2 E-122 Connects the Toner Full Sensor and TNR FULL/FSR Harness.
144 2 H-121 Connects the EEPROM Board and EEPROM Harness.
151 2 H-120 Connects the Laser Unit and ROS Harness.
154 3 F-142 Not Connected
160 2 I-128 Connects the LVPS and AC Inlet.
161 2 I-126 Connects the LVPS and Interlock Switch.
162 2 I-128 Connects the LVPS and FSR/ADC Harness.
163 2 I-126 Connects the LVPS and 24 V Harness.
164 2 I-127 Connects the LVPS and LV PRG Harness.
165 2 I-127 Connects the LVPS and LV Harness.
166 2 I-126 Connects the LVPS and Rear Fan.
167 2 I-126 Not Connected
171 4 G-154 Connects the Option Feeder and OPFPLG Harness.
181 3 E-138 Connects the Registration Sensor and REGI SNS Harness.
190 3 F-138 Connects the Tray 1 (MPT) Turn Clutch and FRONTCLH.
191 3 G-143 Connects the Engine Control Board and EEPROM Harness.
192 3 F138 Connects the Registration Clutch and FRONTCLH Harness.
220 1 C-106 Connects the Control Panel and Control Panel Harness.
CN1 4 B-153 Connects the Temperature/Humidity Sensor and TMP Harness.
311 3 G-142 Connects the Engine Control Board and LV RPG Harness.
Print Engine Plug/Jack Designators (Continued)
P/J Map Coordinates Remarks
