Xerox Phaser 6500 Service Manual

I – 6 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Index
Motor
Automatic Document Feeder (ADF), 2-65, 2-69
feed drive assembly, 2-36
main drive assembly, 2-36
sub drive assembly, 2-36
toner, 2-34
Motor Test
ADF, 4-65
FB (flatbed), 4-64
N
Network
settings, 4-81
Network connector
location, SFP, 1-6
MFP, 1-7
No Paper Actuator
part number, 9-58
No Paper Sensor
Optional Feeder
removal, 8-186
removal, 8-79
tray, 2-22
troubleshooting, Tray 1, 4-21
No Paper Sensor Actuator
Optional Feeder, removal, 8-188
removal, 8-84
NVRAM
initializing, 6-6
location (MFP), 2-42
location (SFP), 2-40
O
Operation Modes, 2-43
Option Drive Clutch
part number, 9-54
removal, 8-174
Option Harness, MFP
part number, 9-17
Option Harness, SFP
part number, 9-17
Optional Feeder, 1-13, 2-24
Board removal, 8-173
cassette assy. part number, 9-60
Chute Cover removal, 8-170
clutch kit part number, 9-54
components, 2-24
disassembly, 8-167 to 8-190
drive clutch, 2-24
Drive Clutch and Bearing removal, 8-174
drive transmission, 2-58
Feed Gear Kit
part number, 9-54
removal, 8-178
Feed Gear removal, 8-175
feed motor, 2-24
part number, 9-54
removal, 8-177
feed roller
operation, 2-24
part number, 9-58
removal, 8-182
feed solenoid, 2-24
operation, 2-24
removal, 8-176
feeder board, 2-24
part number, 9-54
Front Cover removal, 8-168
Left Side Cover removal, 8-169
no paper sensor, 2-24
part number, 9-58
removal, 8-186
No Paper Sensor removal, 8-186
Optional Feeder Harness
part number, 9-56
removal, 8-179
paper path sensor, 2-24
removal, 8-187
part number, 9-52
Rear Cover removal, 8-171
registration bearing
part number, 9-56
Registration Input Actuator, 8-185
registration input actuator
part number, 9-58
Registration Roller Bearing removal, 8-181
Registration Roller removal, 8-183
registration sensor
part number, 9-58
removal, 8-187
removal, 8-167
Right Side Cover removal, 8-172
separator holder
part number, 9-60
removal, 8-190
Outer Pole Cover removal, MFP, 8-39
Output tray, 1-2
Output Tray Extension, SFP
part number, 9-6
removal, 8-16
http://www.manuals4you.com

Xerox Phaser 6500 Specifications

General

Monthly Duty Cycle	Up to 40, 000 pages
Duplex Printing	Manual
Print Technology	Laser
Maximum Print Resolution	600 x 600 x 4 dpi
First Page Out Time	As fast as 12 seconds
Connectivity	USB 2.0, Ethernet
Paper Capacity	250 sheets + 1 sheet bypass tray
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 24 ppm (color) / Up to 24 ppm (black)
