Xerox Phaser 6500 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only I – 5
Index
L
LAN Connector
location, SFP, 1-6
Laser Diode
operation, 2-32
Laser Unit, 2-5
cleaning, 7-3
components, 2-32
light quantity control, 2-43
location, 2-32
operation, 2-5, 2-32
part number, 9-22
removal, MFP, 8-92
removal, SFP, 8-86
Left Front Holder
removal, 8-30
Left Imaging Unit Restraint Block
part number, 9-22
removal, 8-95
Left Side Cover
part number, MFP, 9-10
part number, SFP, 9-6
Left Side Cover removal, MFP, 8-37
Left Side Cover, SFP
removal, 8-18
Left Side Harness
part number, SFP & MFP, 9-17
life count
Fuser, 6-10
Imaging Unit, 6-10
Toner Cartridge, 6-10
Transfer Belt, 6-10
Linearity, 5-53
Link Spring removal, SFP, 8-23
Lower Link Pivot Shaft, SFP
part number, 9-8
Lower Scanner Cover removal, 8-46
LVPS, 2-38
location, 2-38
overcurrent protection, 4-68
overvoltage protection, 4-68
part number, MFP, 9-36
part number, SFP, 9-32
removal, MFP, 8-145
removal, SFP, 8-124
testing, 4-69
M
Magnification, 5-54
Main Drive Assembly, 2-36
location, 2-36
part number, 9-28
removal, 8-114
testing, 4-29
Main firmware
update, A-17
Maintenance items
replacement, 8-6 to 8-14
Maintenance tools, 7-2
Manual Feed, 1-4, 1-5
no paper sensor
removal, 8-78
no paper sensor actuator
part number, 9-19
removal, 8-82
no paper sensor operation, 2-27
registration sensor operation, 2-27
MCU Board, 2-39
location, 2-38
operation, 2-39
part number, MFP, 9-38
part number, SFP, 9-32
removal, MFP, 8-160
removal, SFP, 8-138
Media
curl, A-14
damage, 5-34
detection, 2-30
drive diagram, 2-14
edge detection, 2-30
grain, A-15
moisture content, A-14
path, 2-15
path, ADF, 2-67
recommended, A-15
sensing, 2-19
size detection, 2-43
texture, A-14
unacceptable, A-15
weight, A-14
Media specifications
ADF, 1-30
Duplex Unit, 1-29
Manual Feed Slot, 1-29
Tray 1, 1-28
Tray 2, 1-28
Memory
connector, 1-6
location (MFP), 2-42
location (SFP), 2-40
maximum, 1-21
minimum, 1-21
part number, 9-30, 9-34
Specifications, 1-21
supported types, 1-12
Menu
diagnostic, 4-9
menu map
Service Mode, 4-9
Menu Map, user
MFP, A-3
SFP, A-2
MFP System Configuration, 2-63
Microswitch, 2-18
Modes
operation, 2-43

Xerox Phaser 6500 Specifications

General

Monthly Duty Cycle	Up to 40, 000 pages
Duplex Printing	Manual
Print Technology	Laser
Maximum Print Resolution	600 x 600 x 4 dpi
First Page Out Time	As fast as 12 seconds
Connectivity	USB 2.0, Ethernet
Paper Capacity	250 sheets + 1 sheet bypass tray
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 24 ppm (color) / Up to 24 ppm (black)
