256 | Interfaces
www.dell.com | support.dell.com
Command
History
Example
Figure 14-23. portmode hybrid Configuration Example
Usage
Information
Figure 14-23 sets a port as hybrid, makes the port a tagged member of VLAN 20, and an untagged
member of VLAN 10, which becomes the native VLAN of the port. The port will now accept:
• untagged frames and classify them as VLAN 10 frames
• VLAN 20 tagged frames
The next figure is an example show output with “Hybrid” as the newly added value for 802.1QTagged.
The options for this field are:
• True—port is tagged
• False—port is untagged
• Hybrid—port accepts both tagged and untagged frames
Version 8.3.16.1 Introduced on MXL 10/40GbE Switch IO Module
FTOS(conf)#interface tengig 0/20
FTOS(conf-if-te-0/20)#no shut
FTOS(conf-if-te-0/20)#portmode hybrid
FTOS(conf-if-te-0/20)#sw
FTOS(conf-if-te-0/20)#int vlan 10
FTOS(conf-if-vl-10)#tag tengig 0/20
FTOS(conf-if-vl-10)#int vlan 20
FTOS(conf-if-vl-20)#untag tengig 0/20
FTOS(conf-if-vl-20)#
