Debugging and Diagnostics | 687
Example 5
Figure 39-7. show hardware stack-unit drops unit (drop summary per port) Command
Example
Example 6
Figure 39-8. show hardware stack-unit drops (drop counters per port) Command
Example
FTOS#show hard stack-unit 0 drops unit 0
PortNumber Ingress Drops IngMac Drops Total Mmu Drops EgMac Drops Egress Drops
10 0 0 00
20 0 0 00
30 0 0 00
40 0 0 00
FTOS#
FTOS#show hardware stack-unit 0 drops unit 0 port 27
--- Ingress Drops ---
Ingress Drops : 0
IBP CBP Full Drops : 0
PortSTPnotFwd Drops : 0
IPv4 L3 Discards : 0
Policy Discards : 0
Packets dropped by FP : 0
(L2+L3) Drops : 0
Port bitmap zero Drops : 0
Rx VLAN Drops : 0
--- Ingress MAC counters---
Ingress FCSDrops : 0
Ingress MTUExceeds : 0
--- MMU Drops ---
HOL DROPS : 0
TxPurge CellErr : 0
Aged Drops : 0
--- Egress MAC counters---
Egress FCS Drops : 0
--- Egress FORWARD PROCESSOR Drops ---
IPv4 L3UC Aged & Drops : 0
TTL Threshold Drops : 0
INVALID VLAN CNTR Drops : 0
L2MC Drops : 0
PKT Drops of ANY Conditions : 0
Hg MacUnderflow : 0
TX Err PKT Counter : 0 25
FTOS#
