C HAPTER 27 | Interface Commands
Cable Diagnostics
– 999 –
EXAMPLE
Console#test cable-diagnostics interface ethernet 1/24
Console#show cable-diagnostics interface ethernet 1/24
Port Type Link Status Pair A (meters) Pair B (meters) Last Update
-------- ---- ----------- ---------------- ---------------- -----------------
Eth 1/25 GE Up OK (21) OK (21) 2009-11-13 09:44:19
Console#
show cable-
diagnostics
This command shows the results of a cable diagnostics test.
SYNTAX
show cable-diagnostics interface [interface]
interface
ethernet unit/port
unit - Unit identifier. (Range: 1)
port - Port number. (Range: 1-28)
COMMAND MODE
Privileged Exec
COMMAND USAGE
◆ The results include common cable failures, as well as the status and
approximate distance to a fault, or the approximate cable length if no
fault is found.
◆ To ensure more accurate measurement of the length to a fault, first
disable power-saving mode on the link partner before running cable
diagnostics.
◆ For link-down ports, the reported distance to a fault is accurate to
within +/- 2 meters. For link-up ports, the accuracy is +/- 10 meters.
EXAMPLE
Console#show cable-diagnostics interface ethernet 1/24
Port Type Link Status Pair A (meters) Pair B (meters) Last Update
-------- ---- ----------- ---------------- ---------------- -----------------
Eth 1/26 GE Up OK (21) OK (21) 2009-11-13 09:44:19
Console#
