C
HAPTER
39
| Multicast Filtering Commands
MLD Filtering and Throttling
– 1250 –
ipv6 mld filter
(Global Configuration)
This command globally enables MLD filtering and throttling on the switch.
Use the no form to disable the feature.
SYNTAX
[no] ipv6 mld filter
DEFAULT SETTING
Disabled
COMMAND MODE
Global Configuration
COMMAND USAGE
â—† MLD filtering enables you to assign a profile to a switch port that
specifies multicast groups that are permitted or denied on the port. An
MLD filter profile can contain one or more, or a range of multicast
addresses; but only one profile can be assigned to a port. When
enabled, MLD join reports received on the port are checked against the
filter profile. If a requested multicast group is permitted, the MLD join
report is forwarded as normal. If a requested multicast group is denied,
the MLD join report is dropped.
â—† MLD filtering and throttling only applies to dynamically learned
multicast groups, it does not apply to statically configured groups.
â—† The MLD filtering feature operates in the same manner when MVR is
used to forward multicast traffic.
EXAMPLE
Console(config)#ipv6 mld filter
Console(config)#
RELATED COMMANDS
show ipv6 mld filter
ipv6 multicast-data-drop Enable multicast data guard mode on a port interface IC
show ipv6 mld filter Displays the MLD filtering status PE
show ipv6 mld profile Displays MLD profiles and settings PE
show ipv6 mld
query-drop
Shows if the interface is configured to drop MLD query
packets
PE
show ipv6 mld throttle
interface
Displays the MLD throttling setting for interfaces PE
Table 161: IGMP Filtering and Throttling Commands (Continued)
Command Function Mode
