â—† Traffic segmentation and normal VLANs can exist simultaneously within
the same switch. Traffic may pass freely between uplink ports in
segmented groups and ports in normal VLANs.
â—† When traffic segmentation is enabled, the forwarding state for the
uplink and downlink ports assigned to different client sessions is shown
below.
â—† When traffic segmentation is disabled, all ports operate in normal
forwarding mode based on the settings specified by other functions
such as VLANs and spanning tree protocol.
â—† Enter the traffic-segmentation command without any parameters to
enable traffic segmentation. Then set the interface members for
segmented groups using the traffic-segmentation uplink/downlink
command.
â—† Enter no traffic-segmentation to disable traffic segmentation and
clear the configuration settings for segmented groups.
EXAMPLE
This example enables traffic segmentation globally on the switch.
Console(config)#traffic-segmentation
Console(config)#
traffic-segmentation
session
This command creates a traffic-segmentation client session. Use the no
form to remove a client session.
SYNTAX
[no] pvlan session session-id
session-id – Traffic segmentation session. (Range: 1-4)
Table 100: Traffic Segmentation Forwarding
Destination
Source
Session #1
Downlinks
Session #1
Uplinks
Session #2
Downlinks
Session #2
Uplinks
Normal
Ports
Session #1
Downlink Ports
Blocking Forwarding Blocking Blocking Blocking
Session #1
Uplink Ports
Forwarding Forwarding Blocking Blocking/
Forwarding
*
* The forwarding state for uplink-to-uplink ports is configured by the traffic-
segmentation uplink-to-uplink command.
Forwarding
Session #2
Downlink Ports
Blocking Blocking Blocking Forwarding Blocking
Session #2
Uplink Ports
Blocking Blocking/
Forwarding
*
Forwarding Forwarding Forwarding
Normal Ports Forwarding Forwarding Forwarding Forwarding Forwarding
