C
HAPTER
17
| Multicast Filtering
Filtering and Throttling IGMP Groups
– 632 –
4. Select the profile to configure, and add a multicast group address or
range of addresses.
5. Click Apply.
Figure 374: Adding Multicast Groups to an IGMP Filtering Profile
To show the multicast groups configured for an IGMP filter profile:
1. Click Multicast, IGMP Snooping, Filter.
2. Select Configure Profile from the Step list.
3. Select Show Multicast Group Range from the Action list.
4. Select the profile for which to display this information.
Figure 375: Showing the Groups Assigned to an IGMP Filtering Profile
CONFIGURING IGMP
FILTERING AND
THROTTLING FOR
INTERFACES
Use the Multicast > IGMP Snooping > Filter (Configure Interface) page to
assign and IGMP filter profile to interfaces on the switch, or to throttle
multicast traffic by limiting the maximum number of multicast groups an
interface can join at the same time.
CLI REFERENCES
◆ "IGMP Filtering and Throttling" on page 1227
COMMAND USAGE
◆ IGMP throttling sets a maximum number of multicast groups that a port
can join at the same time. When the maximum number of groups is
reached on a port, the switch can take one of two actions; either “deny”
