C
HAPTER
14
| Basic Administration Protocols
Connectivity Fault Management
– 534 –
◆ MEP ID – Identifier for a maintenance end point which exists on
another CFM-enabled device within the same MA. (Range: 1-8191)
WEB INTERFACE
To configure a remote maintenance end point:
1. Click Administration, CFM.
2. Select Configure Remote MEP from the Step list.
3. Select Add from the Action list.
4. Select an entry from MD Index and MA Index.
5. Specify the remote MEPs which exist on other devices within the same
MA.
6. Click Apply.
Figure 306: Configuring Remote Maintenance End Points
To show the configured remote maintenance end points:
1. Click Administration, CFM.
2. Select Configure MEP from the Step list.
3. Select Show from the Action list.
4. Select an entry from MD Index and MA Index.
Figure 307: Showing Remote Maintenance End Points
