C
HAPTER
14
| Basic Administration Protocols
OAM Configuration
– 559 –
WEB INTERFACE
To initiate a loop back test to the peer device attached to the selected port:
1. Click Administration, OAM, Remote Loop Back.
2. Select Remote Loopback Test from the Action list.
3. Select the port on which to initiate remote loop back testing, enable the
Loop Back Mode attribute, and click Apply.
4. Set the number of packets to send and the packet size, and then click
Test.
Figure 323: Running a Remote Loop Back Test
DISPLAYING RESULTS
OF
REMOTE LOOP
BACK TESTING
Use the Administration > OAM > Remote Loop Back (Show Test Result)
page to display the results of remote loop back testing for each port for
which this information is available.
CLI REFERENCES
â—† "show efm oam remote-loopback interface" on page 1371
PARAMETERS
These parameters are displayed:
◆ Port – Port identifier. (Range: 1-12/26)
◆ Packets Transmitted – The number of loop back frames transmitted
during the last loop back test on this interface.
◆ Packets Received – The number of loop back frames received during
the last loop back test on this interface.
◆ Loss Rate – The percentage of packets transmitted for which there
was no response.
