C
HAPTER
17
| Multicast Filtering
Multicast VLAN Registration for IPv6
– 663 –
◆ Upstream Source IPv6 – The source IPv6 address assigned to all
MVR6 control packets sent upstream on the specified domain. This
parameter must be a full IPv6 address including the network prefix and
host address bits. By default, all MVR6 reports sent upstream use a null
source IP address.
All IPv6 addresses must be according to RFC 2373 “IPv6 Addressing
Architecture,” using 8 colon-separated 16-bit hexadecimal values. One
double colon may be used in the address to indicate the appropriate
number of zeros required to fill the undefined fields. (Note that the IP
address ff02::X is reserved.)
WEB INTERFACE
To configure settings for an MVR6 domain:
1. Click Multicast, MVR6.
2. Select Configure Domain from the Step list.
3. Select a domain from the scroll-down list.
4. Enable MVR6 for the selected domain, select the MVR6 VLAN, set the
forwarding priority to be assigned to all ingress multicast traffic, and
set the source IP address for all control packets sent upstream as
required.
5. Click Apply.
Figure 401: Configuring Domain Settings for MVR6
CONFIGURING MVR6
GROUP ADDRESS
PROFILES
Use the Multicast > MVR6 (Configure Profile and Associate Profile) pages to
assign the multicast group address for required services to one or more
MVR6 domains.
CLI REFERENCES
◆ "MVR for IPv6" on page 1277
