Configuring Protocol-based VLANs
– 1154 –
To configure protocol-based VLANs, follow these steps:
1. First configure VLAN groups for the protocols you want to use
(page 1132). Although not mandatory, we suggest configuring a
separate VLAN for each major protocol running on your network.
Do not add port members at this time.
2. Create a protocol group for each of the protocols you want to assign to
a VLAN using the protocol-vlan protocol-group command (Global
Configuration mode).
3. Then map the protocol for each interface to the appropriate VLAN using
the protocol-vlan protocol-group command (Interface Configuration
mode).
protocol-vlan
protocol-group
(Configuring Groups)
This command creates a protocol group, or to add specific protocols to a
group. Use the no form to remove a protocol group.
SYNTAX
protocol-vlan protocol-group group-id [{add | remove}
frame-type frame protocol-type protocol]
no protocol-vlan protocol-group group-id
group-id - Group identifier of this protocol group.
(Range: 1-2147483647)
frame
27
- Frame type used by this protocol. (Options: ethernet,
rfc_1042, llc_other)
protocol - Protocol type. The only option for the llc_other frame type
is ipx_raw. The options for all other frames types include: arp, ip,
ipv6, rarp.
DEFAULT SETTING
No protocol groups are configured.
COMMAND MODE
Global Configuration
show protocol-vlan
protocol-group
Shows the configuration of protocol groups PE
show interfaces protocol-
vlan protocol-group
Shows the interfaces mapped to a protocol group and
the corresponding VLAN
PE
Table 141: Protocol-based VLAN Commands (Continued)
Command Function Mode
27. SNAP frame types are not supported by this switch due to hardware limitations.
