| Security Measures
Web Authentication
– 328 –
◆ Host IP Address – Indicates the IP address of each connected host.
◆ Remaining Session Time – Indicates the remaining time until the
current authorization session for the host expires.
◆ Apply – Enables web authentication if the Status box is checked.
◆ Revert – Restores the previous configuration settings.
◆ Re-authenticate – Ends all authenticated web sessions for selected
host IP addresses in the Authenticated Host List, and forces the users
to re-authenticate.
WEB INTERFACE
To enable web authentication for a port:
1. Click Security, Web Authentication.
2. Select Configure Interface from the Step list.
3. Set the status box to enabled for any port that requires web
authentication, and click Apply
4. Mark the check box for any host addresses that need to be re-
authenticated, and click Re-authenticate.
Figure 174: Configuring Interface Settings for Web Authentication
