C
HAPTER
45
| IP Interface Commands
IPv4 Interface
– 1396 –
BASIC IPV4
C
ONFIGURATION
This section describes commands used to configure IP addresses for VLAN
interfaces on the switch.
ip address This command sets the IPv4 address for the currently selected VLAN
interface. Use the no form to restore the default IP address.
SYNTAX
ip address {ip-address netmask [secondary]
[default-gateway ip-address] | bootp | dhcp}
no ip address [ip-address netmask [secondary] | dhcp]
ip-address - IP address
netmask - Network mask for the associated IP subnet. This mask
identifies the host address bits used for routing to specific subnets.
The network mask can be either in the traditional format
xxx.xxx.xxx.xxx or use classless format with the range /5 to /32.
For example the subnet 255.255.224.0 would be /19.
secondary - Specifies a secondary IP address.
default-gateway - The default gateway. (Refer to the ip default-
gateway command which provides the same function.)
bootp - Obtains IP address from BOOTP.
dhcp - Obtains IP address from DHCP.
DEFAULT SETTING
DHCP
COMMAND MODE
Interface Configuration (VLAN)
COMMAND USAGE
â—† An IP address must be assigned to this device to gain management
access over the network or to connect the switch to existing IP subnets.
A specific IP address can be manually configured, or the switch can be
Table 195: Basic IP Configuration Commands
Command Function Mode
ip address Sets the IP address for the current interface IC
ip default-gateway Defines the default gateway through which this switch
can reach other subnetworks
GC
show ip default-gateway Displays the default gateway configured for this device PE
show ip interface Displays the IP settings for this device PE
show ip traffic Displays statistics for IP, ICMP, UDP, TCP and ARP
protocols
PE
traceroute Shows the route packets take to the specified host PE
ping Sends ICMP echo request packets to another node on
the network
NE, PE
