C
HAPTER
21
| SNMP Commands
SNMP Target Host Commands
– 781 –
To send an inform to a SNMPv3 host, complete these steps:
1. Enable the SNMP agent (page 775).
2. Create a local SNMPv3 user to use in the message exchange
process (page 785).
3. Create a view with the required notification messages (page 786).
4. Create a group that includes the required notify view (page 784).
5. Allow the switch to send SNMP traps; i.e., notifications (page 778).
6. Specify the target host that will receive inform messages with the
snmp-server host command as described in this section.
â—† The switch can send SNMP Version 1, 2c or 3 notifications to a host IP
address, depending on the SNMP version that the management station
supports. If the snmp-server host command does not specify the
SNMP version, the default is to send SNMP version 1 notifications.
â—† If you specify an SNMP Version 3 host, then the community string is
interpreted as an SNMP user name. The user name must first be
defined with the snmp-server user command. Otherwise, an SNMPv3
group will be automatically created by the snmp-server host
command using the name of the specified community string, and
default settings for the read, write, and notify view.
EXAMPLE
Console(config)#snmp-server host 10.1.19.23 batman
Console(config)#
RELATED COMMANDS
snmp-server enable traps (778)
snmp-server
enable port-traps
mac-notification
This command enables the device to send SNMP traps (i.e., SNMP
notifications) when a dynamic MAC address is added or removed. Use the
no form to restore the default setting.
SYNTAX
[no] snmp-server enable port-traps mac-notification
mac-notification - Keyword to issue trap when a dynamic MAC
address is added or removed.
DEFAULT SETTING
Disabled
COMMAND MODE
Interface Configuration (Ethernet, Port Channel)
COMMAND USAGE
This command can enable MAC authentication traps on the current
interface only if they are also enabled at the global level with the snmp-
server enable traps mac-authentication command.
