C
HAPTER
39
| Multicast Filtering Commands
MVR for IPv4
– 1271 –
MVR Current Learned Groups : 10
MVR Upstream Source IP : 192.168.0.3
.
.
.
show mvr
associated-profile
This command shows the profiles bound the specified domain.
SYNTAX
show mvr [domain domain-id] associated-profile
domain-id - An independent multicast domain. (Range: 1-5)
DEFAULT SETTING
Displays profiles bound to all MVR domains.
COMMAND MODE
Privileged Exec
EXAMPLE
The following displays the profiles bound to domain 1:
Console#show mvr domain 1 associated-profile
Domain ID : 1
MVR Profile Name Start IP Addr. End IP Addr.
-------------------- --------------- ---------------
rd 228.1.23.1 228.1.23.10
testing 228.2.23.1 228.2.23.10
Console#
Table 163: show mvr - display description
Field Description
MVR 802.1p Forwarding
Priority
Priority assigned to multicast traffic forwarded into the MVR VLAN
MVR Proxy Switching Shows if MVR proxy switching is enabled
MVR Robustness Value Shows the number of reports or query messages sent when proxy
switching is enabled
MVR Proxy Query Interval The interval at which the receiver port sends out general queries
MVR Source Port Mode Shows if the switch only forwards multicast streams which the
source port has dynamcially joined or always forwards multicast
streams
MVR Domain An independent multicast domain.
MVR Config Status Shows if MVR is globally enabled on the switch.
MVR Running Status Indicates whether or not all necessary conditions in the MVR
environment are satisfied. (Running status is true as long as MVR
Status is enabled, and the specified MVR VLAN exists.)
MVR Multicast VLAN Shows the VLAN used to transport all MVR multicast traffic.
MVR Current Learned
Groups
The current number of MVR group addresses
MVR Upstream Source IP The source IP address assigned to all upstream control packets.
