C
HAPTER
27
| Interface Commands
Transceiver Threshold Configuration
– 993 –
transceiver-
threshold
temperature
This command sets thresholds for the transceiver temperature which can
be used to trigger an alarm or warning message.
SYNTAX
transceiver-threshold temperature {high-alarm | high-warning
| low-alarm | low-warning} threshold-value
high-alarm – Sets the high temperature threshold for an alarm
message.
high-warning – Sets the high temperature threshold for a warning
message.
low-alarm – Sets the low temperature threshold for an alarm
message.
low-warning – Sets the low temperature threshold for a warning
message.
threshold-value – The threshold of the transceiver temperature.
(Range: -12800 - 12800 in units of 0.01 Celsius)
DEFAULT SETTING
High Alarm: 75.00 °C
HIgh Warning: 70.00
°C
Low Alarm: -123.00
°C
Low Warning: 0.00
°C
COMMAND MODE
Interface Configuration (Ethernet)
COMMAND USAGE
◆ Refer to the Command Usage section under the transceiver-threshold
current command for more information on configuring transceiver
thresholds.
◆ Trap messages enabled by the transceiver-monitor command are sent
to any management station configured by the snmp-server host
command.
EXAMPLE
The following example sets alarm thresholds for the transceiver
temperature at port 1.
Console(config)interface ethernet 1/1
Console(config-if)#transceiver-threshold temperature low-alarm 97
Console(config-if)#transceiver-threshold temperature high-alarm -83
Console#
